| Ref | Part Number | Description |
|---|
| 1 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 2 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 3 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 3 |
703-1623 |
BRACKET-TRANS.DUMP VALVE Not Available Price: |
| 4 |
32105-2 |
SCREW-SHWH Price: $3.49 |
| 4 |
703-1624 |
TRANSMISSION BRACKET Not Available Price: |
| 5 |
66-0120 |
KNOB Price: $5.53 |
| 5 |
710-3195 |
Screw, Hex Cap, 5/16-18 X 4.5 Lg GR5 Price: $6.38 |
| 6 |
924708 |
PRESSURE FILTER ASSEMBLY This part replaces 95-0597. Price: $424.12 |
| 6 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 7 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 7 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 8 |
703-1636 |
BRACKET, TORQUE Not Available Price: |
| 8 |
94-6821 |
CLAMP-WIRE Price: $3.32 |
| 9 |
710-0216 |
Bolt, 3/8 X 3/4 Type 5 This part replaces 710-3000. Price: $3.93 |
| 9 |
95-0648 |
DECAL Price: $14.49 |
| 10 |
726-3008 |
Clip, Cable Price: $4.26 |
| 11 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 11 |
99-1646 |
DISCONTINUED Price: Call Us |
| 12 |
712-3017 |
HEX NUT 3/8-16 GR5 Price: $3.90 |
| 12 |
83-0020 |
SWITCH-IGNITION Price: $56.91 |
| 13 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 13 |
710-3193 |
U-BOLT 5/16-18X1.75 Not Available Price: |
| 14 |
3219-3 |
NUT-HEX Price: $0.34 |
| 14 |
736-0242 |
Washer, Bell, .345 X .88 X .060 Thk Price: $3.75 |
| 15 |
112-7688 |
CONTROL-THROTTLE This part replaces 95-0598. Price: $34.68 |
| 15 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
| 16 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 16 |
703-1629 |
ASSEMBLY-DUMP VALVE Not Available Price: |
| 17 |
28-4210 |
SOLENOID Price: $63.91 |
| 17 |
703-0310 |
DUMP LEVER Not Available Price: |
| 18 |
715-3008 |
SPRING PIN1/8X 3/4 HVY Not Available Price: |
| 18 |
95-5825 |
WIRE ASM Price: $29.70 |
| 19 |
732-3054 |
COMPRESSION SPRING Not Available Price: |
| 19 |
95-0599 |
WIRE ASM Price: $45.86 |
| 20 |
32104-95 |
SCREW-HWH This part replaces 32104-42. Price: $0.41 |
| 20 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 21 |
720-3017 |
Knob, Ball, 1/4-20 Trd Price: $12.87 |
| 22 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 23 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 24 |
3219-14 |
NUT-HEX Price: $0.25 |
| 25 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 26 |
218-461 |
NUT-HH Price: $2.50 |
| 27 |
3254-5 |
WASHER-LOCK Price: $0.49 |
| 32 |
3255-20 |
WASHER-LOCK Price: $0.25 |
| 33 |
3217-25 |
NUT-HEX Price: $0.25 |
| 34 |
95-0574 |
DISCONTINUED Price: Call Us |
| 506915601 |
532141226 |
COVER SWITCH KEY This part replaces 506915601. Price: $4.99 |
| 506917102 |
506917103 |
IGNITION SWITCH This part replaces 506917102. Price: $37.99 |
| 506917301 |
532124211 |
NUT IGNITION This part replaces 506917301. Price: $4.99 |
| 516844600 |
516844602 |
KEY SET This part replaces 516844600. Price: $12.99 |
| 722782902 |
722782902 |
RIVET Price: $3.99 |
