| Ref | Part Number | Description |
|---|
| 1 |
3217-9 |
NUT-HH Price: $0.37 |
| 1 |
539104761 |
GREASE ZERK LONG Price: $2.99 |
| 2 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 2 |
539101232 |
BUSHING, FLANGED Price: $11.99 |
| 3 |
24-9830-01 |
AXLE SUPPORT ASM This part replaces 24-9830. Price: $83.43 |
| 3 |
539104760 |
DECK LIFT SPRING Price: $5.99 |
| 4 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 4 |
539105050 |
LIFT LINKAGE,PAINTED Price: $23.99 |
| 5 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
539104310 |
CONNECTING LINK Price: $22.99 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
539132170 |
LIFT SHAFT ASM, FRONT Price: $219.99 |
| 7 |
539108354 |
SHAFT LIFT REAR Price: $108.99 |
| 7 |
67-8170 |
DISCONTINUED Price: Call Us |
| 8 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 8 |
539104323 |
ADJ. PLATE PAINTED Price: $23.99 |
| 9 |
539104321 |
ADJ. PLATE WLDMNT Price: $63.99 |
| 9 |
67-8130 |
DISCONTINUED Price: Call Us |
| 10 |
32128-23 |
NUT-HF Price: $1.51 |
| 10 |
539104530 |
DECK LIFT SPACER Price: $5.99 |
| 11 |
539104808 |
PILLOW BLOCK Price: $7.99 |
| 11 |
98-3869-01 |
WEIGHT-REAR This part replaces 67-8960. Price: $461.69 |
| 12 |
584392702 |
REINFORCEMENT.PLATEX431 This part replaces 539104807. Price: $11.99 |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 14 |
32146-20 |
NUT-HEX Price: $3.23 |
| 14 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 15 |
539101982 |
EYEBOLT, RH Price: $37.99 |
| 15 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 16 |
539101802 |
E-RING 7/8 Price: $2.99 |
| 16 |
71-4850 |
DISCONTINUED Price: Call Us |
| 17 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 17 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 18 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 18 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 19 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 19 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 20 |
237-22 |
O-RING Price: $2.43 |
| 20 |
539976982 |
WASHER 5/8 FLAT Price: $3.99 |
| 21 |
539990654 |
COTTER PIN Price: $2.99 |
| 21 |
71-4430 |
REAR STEERING HOSE Price: $104.39 |
| 22 |
539105060 |
CLEVIS PIN Price: $4.99 |
| 22 |
68-9710 |
HOSE-STEERING, REAR Price: $98.31 |
| 23 |
328-25 |
SCREW-HH Price: $4.07 |
| 23 |
539107476 |
BOLT 3/8-16 X 1.0 Price: $5.99 |
| 24 |
2412-39 |
CLAMP-R Price: $1.70 |
| 24 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 25 |
32128-21 |
NUT-HF Price: $0.39 |
| 25 |
539105059 |
LANYARD Price: $4.99 |
| 26 |
596917701 |
Pins This part replaces 539102526. Price: $4.99 |
| 26 |
68-6950 |
CROSS MEMBER WA *B Price: $311.34 |
| 27 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 27 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 28 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 28 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 29 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 29 |
539108322 |
LIFT LEVER WELDMENT Price: $84.99 |
| 30 |
237-78 |
O-RING Price: $3.85 |
| 30 |
539102515 |
GRIP Price: $3.99 |
| 31 |
32128-45 |
NUT-HHF Price: $7.67 |
| 31 |
539101050 |
GRIP Price: $2.99 |
| 32 |
539104523 |
PIN Price: $7.99 |
| 32 |
68-6860 |
DISCONTINUED Price: Call Us |
| 33 |
539106532 |
ROLL PIN Price: $2.99 |
| 34 |
539103534 |
PIN MT, UPPER Price: $22.99 |
| 35 |
539101058 |
SPRING Price: $3.99 |
| 36 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 37 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 38 |
539111075 |
DECK STOP Price: $11.99 |
| 39 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
