| Ref | Part Number | Description |
|---|
| 1 |
37-3770 |
SELF-LOCKING NUT Price: $2.16 |
| 1 |
530035017 |
Screw - Pump Cover Price: $0.99 |
| 2 |
37-3840 |
LH PLT/GUIDE ASM Price: $405.36 |
| 2 |
530035191 |
Pump Cover Ass'y (Inc.4) Price: $3.99 |
| 3 |
37-3710 |
ANCHOR POST BSHG Price: $13.19 |
| 3 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 4 |
37-3970 |
DISCONTINUED Price: Call Us |
| 4 |
530035156 |
Screw - Idle Adjustment Price: $1.99 |
| 5 |
19-6460 |
DISCONTINUED Price: Call Us |
| 6 |
19-6450 |
DISCONTINUED Price: Call Us |
| 6 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 7 |
37-4040 |
DISCONTINUED Price: Call Us |
| 7 |
530035133 |
Valve - Throttle Price: $3.33 |
| 8 |
530035007 |
Clip - Throttle Shaft Price: Call Us |
| 9 |
530035138 |
Spring - Throttle Return Price: Call Us |
| 11 |
530035132 |
Shaft Assembly - Throttle Price: Call Us |
| 12 |
37-4010 |
DISCONTINUED Price: Call Us |
| 12 |
530035023 |
Spring - Idle Needle Price: $0.99 |
| 13 |
37-4020 |
Shoe Lining Pic L.H. Price: Call Us |
| 13 |
530035141 |
Needle - Idle Price: $2.99 |
| 14 |
37-3560 |
Shoe Lining Sec. L.H. Price: Call Us |
| 17 |
37-3690 |
LH LEVER/CAM PLT PKG Price: $13.16 |
| 17 |
530035036 |
Spring - Hi Speed Needle Price: Call Us |
| 18 |
37-3780 |
CABLE GUIDE Price: $8.13 |
| 18 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 19 |
37-3630 |
LH PARKING BRAKE LEVR Price: $44.53 |
| 20 |
37-3620 |
DISCONTINUED Price: Call Us |
| 20 |
530035016 |
Screw - Metering Lever Pin Price: $2.99 |
| 21 |
37-3600 |
RETAINER WASHER Price: $2.31 |
| 21 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 22 |
37-3610 |
ANCHOR BOLT Price: $3.73 |
| 22 |
530035042 |
Plate - Circuit Price: $3.33 |
| 23 |
52-7920 |
DISCONTINUED This part replaces 37-3990. Price: Call Us |
| 24 |
37-3790 |
DISCONTINUED Price: Call Us |
| 24 |
530035151 |
Gasket - Metering Diaphragm Price: $1.99 |
| 25 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 26 |
530035153 |
Screw Assembly - Metering Cover & Throttle Shaft Clip Price: $3.33 |
| 27 |
37-3800 |
DISCONTINUED Price: Call Us |
| 27 |
530035149 |
Cover - Metering Diaphragm Price: $3.33 |
| 28 |
37-4000 |
SHOE TO SHOE SPRING Price: $8.44 |
| 28 |
530035185 |
Kit - Carb. Kwik Repair Kit Price: $24.99 |
| 29 |
38-3830 |
DISCONTINUED Price: Call Us |
| 30 |
37-3940 |
DISCONTINUED X-REF Price: Call Us |
| 31 |
37-3950 |
ADJ NUT WASHER Price: $3.13 |
| 32 |
37-3900 |
DISCONTINUED X-REF Price: Call Us |
| 33 |
37-3930 |
DISCONTINUED-SEE NOTE Price: Call Us |
| 34 |
37-3820 |
ADJ LEVER PIN Price: $13.19 |
| 35 |
37-3960 |
DISCONTINUED Price: Call Us |
| 36 |
37-3980 |
DISCONTINUED Price: Call Us |
