| Ref | Part Number | Description |
|---|
| 1 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 1 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 2 |
117-5109 |
HYD CYLINDER ASM Price: $860.92 |
| 2 |
725249751 |
SCREW Price: $4.99 |
| 3 |
100-4930-03 |
CARRIER ASM Price: $1,127.30 |
| 3 |
574379201 |
NEEDS DESCRIPTION Price: Call Us |
| 4 |
32128-33 |
NUT-HF Price: $0.25 |
| 4 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 5 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 5 |
525398001 |
NEEDS DESCRIPTION Price: Call Us |
| 6 |
721434701 |
PIN Price: $2.99 |
| 6 |
95-8822 |
HOSE-HYD Price: $139.11 |
| 7 |
506887801 |
SPACER Price: $7.99 |
| 7 |
99-3433 |
WIRE-CENTER Price: $19.58 |
| 8 |
117-5147 |
HOSE ASM-HYD Price: $127.03 |
| 8 |
738210404 |
BALL BEARING 6004-2RS1 Price: $9.99 |
| 10 |
734115441 |
WASHER - 26X6.5X1.6 Price: $0.99 |
| 11 |
535475212 |
SCREW EHHFM Price: $2.99 |
| 11 |
95-8519-0P |
BRACKET - SLIDE *B This part replaces 95-8519-03. Price: $54.33 |
| 12 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 12 |
575585802 |
NEEDS DESCRIPTION Price: Call Us |
| 13 |
732211601 |
LOCKNUT M6 Price: $4.99 |
| 13 |
95-8538 |
SLIDE-PLASTIC Price: $14.81 |
| 14 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
578184001 |
NEEDS DESCRIPTION Price: Call Us |
| 15 |
576492502 |
PULLEY Price: $27.99 |
| 15 |
95-8531 |
SHAFT-PIVOT, LIFTARM Price: $139.66 |
| 16 |
325-10 |
SCREW-HH Price: $1.82 |
| 16 |
734117441 |
WASHER Price: $3.99 |
| 17 |
506675402 |
BOLT Price: $5.99 |
| 17 |
95-8532-03 |
LINK-SHAFT, PIVOT Price: $15.72 |
| 18 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 18 |
501604801 |
WIRE ASSY This part replaces 577199901. Price: $24.99 |
| 19 |
325-19 |
SCREW-HH Price: $2.57 |
| 19 |
731232001 |
Nut This part replaces 731232051. Price: $3.99 |
| 20 |
104-4865 |
CAP-BEARING Price: $56.97 |
| 20 |
525404301 |
GUIDE RAIL Price: $17.99 |
| 21 |
3218-5 |
NUT-JAM Price: $0.27 |
| 21 |
535475212 |
SCREW EHHFM This part replaces 725236861. Price: $2.99 |
| 22 |
325-7 |
SCREW-HH Price: $1.53 |
| 22 |
732212001 |
NUT This part replaces 732212051. Price: $3.99 |
| 23 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 23 |
506554701 |
LINK Price: $4.99 |
| 24 |
506554601 |
STEERING CHAIN Price: $17.99 |
| 24 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 25 |
506671901 |
SPRING Price: $22.99 |
| 25 |
99-3373 |
BAR-SUPPORT, SLIDE Price: $9.76 |
| 26 |
578184301 |
NEEDS DESCRIPTION Price: Call Us |
| 26 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 27 |
578184101 |
NEEDS DESCRIPTION Price: Call Us |
| 27 |
75-9590 |
SPACER-CYLINDER Price: $6.55 |
| 28 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 28 |
506597401 |
BOLT Price: $5.99 |
| 29 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 29 |
535423801 |
BOLT Price: $4.99 |
| 30 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 30 |
99-3640 |
TUBE ASM Price: $127.70 |
| 31 |
340-78 |
NUT-LOCK Price: $1.63 |
| 32 |
99-3492 |
ROD-FORMED, HOSE GUARD Price: $25.26 |
| 33 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 34 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 35 |
98-7981 |
CHAIN-LINK, STRAIGHT Price: $11.44 |
| 36 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 37 |
99-3550 |
CLIP-LINK Price: $10.13 |
| 38 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 39 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
