| Ref | Part Number | Description |
|---|
| 1 |
4171R |
Clip, Insulated Price: Call Us |
| 1 |
98-7433 |
MAIN BEARING CASE ASM Price: $290.88 |
| 2 |
74520636 |
Bolt, Hex 3/8-16 x 2-1/4 Grade 5 Price: Call Us |
| 2 |
98-7434 |
BOLT-CASE, BEARING Price: $13.26 |
| 3 |
98-7435 |
GASKET-CASE, BEARING Price: $19.37 |
| 4 |
98-7436 |
COVER-CASE, BEARING Price: $71.61 |
| 5 |
74760622 |
Bolt. Hex 3/8-16 x 1-3/8 Price: Call Us |
| 5 |
98-7437 |
GASKET-CASE COVER, BEARING Price: $11.13 |
| 6 |
19131407 |
Washer 13/32 x 7/8 x 7 Ga. Price: Call Us |
| 6 |
98-7438 |
BOLT Price: $1.15 |
| 7 |
98-7439 |
BOLT Price: $1.00 |
| 8 |
98-7440 |
SEAL-OIL Price: $61.88 |
| 9 |
98-7441 |
MAIN BEARING CASE ASM Price: $153.74 |
| 10 |
10040600 |
Washer, Lock Price: Call Us |
| 10 |
98-7442 |
MAIN BEARING CASE ASM Price: $153.74 |
| 11 |
74760620 |
Bolt, Hex 3/8-16 x 1-1/4 Price: Call Us |
| 11 |
98-7443 |
MAIN BEARING CASE ASM Price: $154.26 |
| 12 |
5950J |
Bushing .384 x 1/2 x 1-1/4 Price: Call Us |
| 13 |
74760614 |
Bolt, Hex 3/8-16 x 7/8 Price: Call Us |
| 14 |
4939M |
Spring, Retainer Price: Call Us |
| 15 |
139276 |
Nyliner Price: Call Us |
| 16 |
138908 |
Arm, Pivot Price: Call Us |
| 17 |
19211621 |
Washer 21/32 x 1 x 21 Ga. Price: Call Us |
| 18 |
138914 |
Rod, Pivot Support Price: Call Us |
| 19 |
138948 |
Pin, Pivot Price: Call Us |
| 20 |
73800600 |
Locknut 3/8-16 Price: Call Us |
| 21 |
19131416 |
Washer 13/32 x 7/8 x 16 Ga. Price: Call Us |
| 22 |
138912 |
Bracket, Pivot Rod Price: Call Us |
| 23 |
138905 |
Link, Lift Price: Call Us |
| 24 |
138947 |
Pin, Pivot Price: Call Us |
| 25 |
138909 |
Spacer Price: Call Us |
| 26 |
127017X |
Harness, Lift Kit Price: Call Us |
| 27 |
8984R |
Switch, Lift Price: Call Us |
| 28 |
7320R |
Nut, Switch Price: Call Us |
| 29 |
7319R |
Washer, Lock Int. Tooth Price: Call Us |
| 30 |
19151216 |
Washer 15/32 x 3/4 x 16 Ga. Price: Call Us |
| 31 |
124371X |
Electric, Actuator Price: Call Us |
| 32 |
105624X |
Hub, Lever Lift Price: Call Us |
| 33 |
677A886 |
Bracket, Assembly Actuator, Gear Drive Price: Call Us |
| 34 |
72270608 |
Bolt, Carriage 3/8-16 x 1 Price: Call Us |
| 35 |
140877 |
Pin, Actuator Price: Call Us |
| 36 |
4940M |
Spring, Retainer Price: Call Us |
| 37 |
74760616 |
Bolt, Hex 3/8-16 x 1 Price: Call Us |
| 38 |
9698R |
Wire, Ground Price: Call Us |
| 46 |
74760520 |
Bolt, Hex 5/16-18 x 1-1/4 Price: Call Us |
