HANDLE
Parts (17)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 33115-035 | SCREW-HH Price: $1.15 |
| 2 | 33115-030 | SCREW-HH Price: $0.68 |
| 3 | 33095-00 | WASHER-FLAT Price: $0.25 |
| 4 | 100-5376-03 | PLATE-END Price: $113.13 |
| 5 | 33025-00 | NUT-LOCK, NI Price: $0.54 |
| 6 | 100-5377 | BEARING-ROLLER Price: $232.19 |
| 7 | 100-5385 | PULLEY-DRIVE Price: $506.81 |
| 8 | 100-5378 | KEY-PULLEY, DRIVE Price: $24.06 |
| 9 | 100-5379 | SHAFT-DRIVE, SHORT Price: $747.84 |
| 10 | 100-3638 | SCREW-SET Price: $9.84 |
| 11 | 100-5381 | GEARBOX Price: $2,702.68 |
| 12 | 100-5380 | KEY-SHAFT, DRIVE Price: $51.95 |
| 13 | 100-3694 | SCREW-HSH Price: $4.69 |
| 14 | 100-7643 | SCREW-SET Price: $1.63 |
| 15 | 100-5382 | SHAFT-DRIVE, LONG Price: $920.83 |
| 16 | 33116-025 | SCREW-HH Price: $0.78 |
| 17 | 3253-7 | WASHER-LOCK Price: $0.27 |
