| Ref | Part Number | Description |
|---|
| 1 |
462069 |
Key Assembly w/Fob Price: Call Us |
| 1 |
483366 |
Key, Ignition Price: Call Us |
| 2 |
48017-04 |
Nut, Hex 5/8-32 Price: Call Us |
| 3 |
48017-03 |
Lockwasher, 5/8" Internal Price: Call Us |
| 4 |
04017-04 |
Bolt, Hex Head Serrated Flange 1/4-20 x 1/2" Price: Call Us |
| 5 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 6 |
462827 |
Instrument Panel w/Decal Price: Call Us |
| 7 |
481544 |
Control Cable Price: Call Us |
| 8 |
04021-26 |
Locknut, #10-24 Price: Call Us |
| 9 |
463034 |
SEALED PTO SWITCH KIT This part replaces 483957. Price: Call Us |
| 10 |
484721 |
Tiger Eye Cluster Gauge Price: Call Us |
| 11 |
48798 |
Switch, Starter Price: Call Us |
| 12 |
482253 |
Diode Price: Call Us |
| 13 |
483013 |
Relay Price: Call Us |
| 14 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 15 |
452291 |
Anti-Rotation Weldment Price: Call Us |
| 16 |
04117-01 |
Nut, Flange Elastic Stop 5/16-18 Price: Call Us |
| 17 |
484373 |
Pulley, 5" OD - 1.125 Bore (SPZ61H) Price: Call Us |
| 18 |
04063-28 |
Key, 1/4 x 1/4 x 3-1/2" Price: Call Us |
| 19 |
484276 |
Clutch, GT3.5 - 1.125 Bore Price: Call Us |
| 20 |
483958 |
Diode, 600V - 6A Price: Call Us |
| 21 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 Price: Call Us |
| 22 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 23 |
04102-03 |
Bolt, Hex Head 7/16-20 x 2-1/4" w/Patch Price: Call Us |
| 24 |
485678 |
Wire Harness Adapter, Kawasaki FX & FT Price: Call Us |
| 25 |
482253 |
Diode Price: Call Us |
| 28 |
483629 |
Fuse Holder Price: Call Us |
| 29 |
48298 |
Fuse, 20 Amp Price: Call Us |
| 30 |
483571 |
Cover, Sealed Double Price: Call Us |
| 31 |
482588 |
Clip, Wire Price: Call Us |
| 32 |
485167 |
Wire Harness, SCZ48/52 Price: Call Us |
| 33 |
484722 |
Wire Harness, Operator Platform Price: Call Us |
| 34 |
481638 |
Switch Price: Call Us |
| 35 |
48029-13 |
Battery Cable, 25" Red (Kawasaki) Price: Call Us |
| 36 |
48029-11 |
Battery Cable, 27" Black Price: Call Us |
| 37 |
04001-44 |
Bolt, Hex Head 1/4-20 x 1/2” Price: Call Us |
