| Ref | Part Number | Description |
|---|
| 0 |
640330 |
CARBURETOR This part replaces 640159. Price: $75.33 |
| 1 |
532141393 |
FENDER/FOOTREST This part replaces 532125141. Price: $106.71 |
| 1 |
640035 |
SHAFT & LEV Price: $7.17 |
| 1A |
36288 |
BUSHING Price: $1.22 |
| 2 |
532109238 |
TUBE BATTERY DRAIN Price: $5.46 |
| 2 |
640036 |
SPRING Price: $1.20 |
| 3 |
532109596 |
HOSE CLAMP T Price: $3.99 |
| 4 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532129965. Price: $24.99 |
| 5 |
532124144 |
PAD FOOTREST Price: $2.96 |
| 5 |
640037 |
WASHER Price: $1.20 |
| 6 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 6 |
640038 |
SHUTTER Price: $1.42 |
| 7 |
532139969 |
HOOD LATCH This part replaces 532131318. Price: $3.45 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 9 |
532130986 |
LENS.LR.LH.HUSQV. Price: $12.99 |
| 10 |
532130985 |
LENS RH Price: $13.22 |
| 10 |
640044 |
SHAFT & LEV Price: $1.55 |
| 11 |
532128449 |
BRK PVT FRAME LH Price: $5.03 |
| 11 |
640045 |
SPRING Price: $1.11 |
| 12 |
532128808 |
BRK PVT FRAME RH Price: $5.03 |
| 13 |
532133384 |
CHASSIS 14GA LR Price: $95.27 |
| 13 |
640037 |
WASHER Price: $1.20 |
| 14 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 14 |
640066 |
SHUTTER This part replaces 640046. Price: $2.60 |
| 15 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 16 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 17 |
532127880 |
DRAW BAR Price: $25.05 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
532127115 |
PLATE This part replaces 532125142. Price: $5.78 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 20 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 21 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 22 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 23 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 24 |
532124602 |
BAR SHIP LOCK Price: $4.42 |
| 25 |
532138314 |
Console, Shift Control Price: Call Us |
| 25 |
640039B |
FLOAT BOWL This part replaces 640039A. Price: $12.66 |
| 25A |
730639 |
BOWL KIT Price: $20.46 |
| 26 |
596135301 |
Washers This part replaces 819091413. Price: $2.99 |
| 27 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 27 |
632544A |
FLOAT SHAFT This part replaces 632544. Price: $2.61 |
| 28 |
632543 |
FLOAT Price: $6.73 |
| 29 |
640047 |
GASKET Price: $2.60 |
| 30 |
632709 |
INLET NEEDLE Price: $4.91 |
| 32 |
611221 |
SOLENOID Price: $41.68 |
| 33 |
27110A |
GASKET This part replaces 640042. Price: $1.45 |
| 36 |
640043 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 37A |
632547 |
O RING Price: $1.49 |
| 38 |
632545 |
SPRING Price: $0.87 |
| 38A |
36918 |
SPRING Price: $1.18 |
| 39 |
640039B |
FLOAT BOWL This part replaces 640048. Price: $12.66 |
| 40 |
640040 |
FUEL JET Price: $1.25 |
