POWER UNIT
Parts (49)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 251-347 | BEARING-BALL Price: $9.69 |
| 3 | 106-6941 | SEAL Price: $5.74 |
| 4 | 106-6942 | V-RING Price: $8.86 |
| 5 | 107-8133 | WASHER-FLAT Price: $3.05 |
| 6 | 107-3505 | SPACER-TOOL, ROLLER Price: $8.20 |
| 106 | 530027140 | Worm Gear Price: $8.99 |
| 107 | 530019147 | Seal Price: $3.99 |
| 108 | 530069217 | Gasket Set Price: $3.33 |
| 109 | 530027128 | Dust Plug Price: $1.99 |
| 110 | 530014204 | Plunger Price: $9.99 |
| 111 | 530027126 | Spring Price: $1.99 |
| 114 | 530015650 | Screw-Pinch Clamp This part replaces 530015871. Price: $1.99 |
| 115 | 530027272 | Oil Pickup & Filter Price: $3.99 |
| 116 | 530027192 | Oiler Intake Line Price: $1.99 |
| 118 | 530032049 | Bearing Price: $8.99 |
| 119 | 530048083 | Drum (Model 3000) Price: $17.99 |
| 119 | 530048084 | Drum Sprocket (Model 2700,2800,3300) Price: $14.99 |
| 120 | 530027161 | Clutch Plate Price: $1.99 |
| 121 | 530014161 | Clutch Ass'y. Price: $9.99 |
| 122 | 530027129 | Oiler Gear Spur Price: $0.99 |
| 124 | 530022312 | Handlebar Ass'y. Price: $10.84 |
| 125 | 530023064 | Bar Adjusting Pin Price: $3.99 |
| 127 | 530016110 | Screw This part replaces 530015730. Price: $0.99 |
| 128 | 530015719 | Bar Stud Price: $1.99 |
| 129 | 530015108 | Vent Pin Price: $1.99 |
| 130 | 952051301 | Chain 16" Price: $24.99 |
| 130 | 952051310 | Chain 20" Price: $24.99 |
| 130 | 952051313 | Chain 18" Price: $21.95 |
| 133 | 530015251 | BAR NUT This part replaces 530015445. Price: $1.99 |
| 134 | 545006011 | SCRENCH This part replaces 530031146. Price: $6.99 |
| 135 | 530027847 | Grip Price: Call Us |
| 136 | 530016058 | Screw Price: $1.99 |
| 137 | 530021061 | Oiler Discharge Line Price: $1.99 |
| 138 | 530002464 | Oiler Discharge Sleeve Price: $1.99 |
| 139 | 530015422 | Tubing Nut Price: $1.99 |
| 140 | 530015752 | Oiler Adjustment Pin Price: $1.99 |
| 141 | 530027222 | Chain Pad - Top Price: $1.99 |
| 142 | 530027223 | Chain Pad Price: $0.99 |
| 143 | 530015733 | Thrust Washer Price: $1.99 |
| 144 | 530052085 | Chain Repair Kit Price: $4.68 |
| 145 | 952044324 | Model 2800 Price: Call Us |
| 145 | 952044325 | Bar 18" Price: $34.95 |
| 145 | 952044326 | Model 2700,3100,3300 Price: $37.95 |
| 145 | 952044372 | Model 3000,3300 Price: $1.00 |
| 145 | 952044377 | Model 3000 Price: Call Us |
| 146 | 530029236 | Crankcase Plug Price: $1.99 |
| 172 | 530024466 | Handguard - See also 65 External Power Unit Price: $11.99 |
| 173 | 530015509 | Screw Price: $1.99 |
| 174 | 530024467 | Handguard Cap Price: $4.99 |
