| Ref | Part Number | Description |
|---|
| 1 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 2 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 3 |
29-6120-03 |
PUMP PLATE ASM This part replaces 29-6120. Price: $93.02 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
251-259 |
BEARING-BALL Price: $13.67 |
| 5 |
532408700 |
DASH.ASM.HUSQ.GT Price: $59.99 |
| 6 |
3210-7 |
SCREW-HH Price: $0.61 |
| 7 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 8 |
322-17 |
SCREW-HH Price: $2.62 |
| 9 |
3219-2 |
NUT-HEX Price: $0.37 |
| 10 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 11 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 12 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 13 |
340-99 |
FITTING-HYD, 90 DEG Price: $32.27 |
| 14 |
110-9695 |
HUB-PUMP This part replaces 33-4380. Price: $55.09 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
3241-5 |
SCREW-SET Price: $0.61 |
| 17 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 18 |
46-6390-03 |
COUPLING-DRIVE ASM This part replaces 46-6390. Price: $80.79 |
| 19 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 20 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 21 |
322-6 |
SCREW-HH Price: $0.45 |
| 22 |
27-6590 |
SPACER-COUPLING, RUBBER Price: $13.38 |
| 23 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 24 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 25 |
322-8 |
SCREW-HH Price: $1.26 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
321-2 |
SCREW-HH Price: $2.79 |
| 27 |
321-4 |
SCREW-HH Price: $0.99 |
| 28 |
54-9300-03 |
COVER-SHAFT, PUMP This part replaces 54-9300. Price: $31.70 |
| 29 |
54-9290 |
BRACKET-MOUNTING Price: $16.99 |
| 30 |
237-80 |
O-RING Price: $6.10 |
| 31 |
68-8660 |
FITTING-HYD, 90 DEG Price: $181.88 |
| 32 |
237-81 |
O-RING Price: $2.76 |
| 33 |
68-8990 |
HEAD-FILTER Price: $153.83 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 34 |
67-8110 |
CARTRIDGE-FILTER, OIL Price: $24.99 |
| 35 |
353-987 |
FITTING-ELBOW, 90 Price: $74.72 |
| 36 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532423694 |
FENDER.TLT.FS.W/CPH/FW/RSF.ORN Price: $179.99 |
| 37 |
68-9650 |
HOSE-AXLE Price: $30.32 |
| 38 |
70-2620 |
FITTING-HYD, 90 DEG Price: $116.72 |
| 39 |
323-7 |
SCREW-HH Price: $0.65 |
| 40 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 41 |
353-508 |
PLUG-HH Price: $7.96 |
| 42 |
99-5697 |
TRANSMISSION ASM This part replaces 71-4370. Price: $4,087.55 |
| 43 |
32120-72 |
RING-SNAP Price: $2.09 |
| 44 |
86-7220 |
GEAR-PINION This part replaces 23-4810. Price: $81.33 |
| 45 |
41-8760 |
GASKET Price: $5.99 |
| 46 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 47 |
321-4 |
SCREW-HH Price: $0.99 |
| 48 |
3217-16 |
NUT-HEX Price: $0.25 |
| 49 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 50 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 51 |
28-9570-03 |
LEVER-PUMP This part replaces 28-9570. Price: $264.06 |
| 52 |
49-2040 |
SCREW-HWHTF This part replaces 11-9760. Price: $1.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 53 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 54 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 55 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 56 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 57 |
237-42 |
O-RING Price: $2.78 |
| 58 |
237-22 |
O-RING Price: $2.43 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 161 |
532439781 |
WINDOW.FUEL.LT.HUSQ.TEX.498 This part replaces 532409627. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
579841501 |
KITS.CHASSIS.WELD.SERVICE This part replaces 532195457. Price: $219.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 199 |
532413485 |
PLATE.DECK.LIFT.HUSQ.LT Price: $9.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 233 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 282 |
532414110 |
CLIP.RETAINER.CONSOLE.LT.HUSQ Price: $2.99 |
| 283 |
532439151 |
CONSOLE.ASM.LFT.RSF.HUSQ.LT This part replaces 532418741. Price: $37.99 |
| 284 |
532439150 |
CONSOLE.SHFT.PDL.CNTRL.HUSQ.LT This part replaces 532417887. Price: $39.99 |
| 285 |
532416315 |
CONSOLE INSERT RH Price: $14.99 |
| 286 |
532416317 |
CONSOLE.INSRT.LH.HUSQ.LT.BLACK Price: $11.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 298 |
532110552 |
Nut, Push Price: Call Us |
