| Ref | Part Number | Description |
|---|
| 1 |
82_755_17 |
Kit-#2 Cylinder Barrel (Incl. Ref. #4-6) Price: Call Us |
| 2 |
52_016_05 |
Valve-Exhaust Price: Call Us |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
52_316_06 |
Guide-Valve Price: Call Us |
| 4 |
52_031_01 |
Inset-Valve Seat Price: Call Us |
| 5 |
X-82-2 |
Nut Price: Call Us |
| 6 |
52_468_12 |
Washer-Flat Price: Call Us |
| 7 |
52_072_12 |
Stud Price: Call Us |
| 8 |
25_086_13 |
Screw-Hex Flange Price: Call Us |
| 9 |
25_086_10 |
Screw-Hex Flange Price: Call Us |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
X-583-5 |
Seal-RearOil Price: Call Us |
| 11 |
X-802-9 |
Screw-Wash Head Price: Call Us |
| 12 |
52_755_57 |
Kit-Closure Plate (Incl. Ref. #13) Price: Call Us |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 13 |
X-75-23 |
Plug Price: Call Us |
| 14 |
52_755_50 |
Kit-Oil Relief Price: Call Us |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 15 |
X-269-43 |
Ring-Retaining Price: Call Us |
| 16 |
52_078_05 |
Shaft-Governor Price: Call Us |
| 18 |
25_086_12 |
Screw-Hex Flange Price: Call Us |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
82_755_16 |
Kit-#1 Cylinder Barrel (Incl. Ref. #4-6) Price: Call Us |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 20 |
X-75-10 |
Plug Price: Call Us |
| 21 |
52_032_10 |
Seal-ReAR Oil Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
52_030_12 |
Bearing-Sleeve .020" Price: Call Us |
| 23 |
X-75-32 |
Plug-Hex Price: Call Us |
| 24 |
5209503 |
Housing-Oil Price: Call Us |
| 25 |
5223702 |
Clip-Spring Price: Call Us |
| 26 |
X-67-64 |
Screw Price: Call Us |
| 27 |
52_237_05 |
Clamp Price: Call Us |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 28 |
X-702-15 |
Plug-Cup Price: Call Us |
| 29 |
52_123_10 |
Tube-Oil Pickup Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
52_139_08 |
Plug Price: Call Us |
| 32 |
25_086_11 |
Screw-Hex Flange Price: Call Us |
| 33 |
41_468_01 |
Washer-Flat Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 52_030_10 |
Bearing-Sleeve |
Price: Call Us 52_030_10 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 This part replaces 532405450. Price: $19.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
