| Ref | Part Number | Description |
|---|
| 1 |
710-04454 |
HEX SCREW #10-32 This part replaces 1186299. Price: $3.71 |
| 2 |
GW-9463 |
Knob-tines/PTO clutch lever, tapered, plastic Price: $10.32 |
| 3 |
GW-2263 |
Detent Plate-tines/PTO clutch lever Price: $45.91 |
| 4 |
777I20945 |
Decal-operating instructions, detent plate Price: $4.38 |
| 5 |
1186349 |
Bolt-flanged hex hd., 3/8-16 x 1-1/2" Price: $3.11 |
| 7 |
710-04043 |
SCREW 5/16-18 This part replaces 1186329. Price: $3.96 |
| 9 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 11 |
GW-9362 |
Pin-spring, 1/8" Price: $3.82 |
| 12 |
GW-9838 |
HEX NUT 1/2-20 Not Available Price: |
| 13 |
GW-9934 |
Washer-shoulder, 1/2" Price: $13.73 |
| 14 |
GW-9932 |
Washer-disc spring Price: $21.54 |
| 15 |
GW-2628 |
LEVER - wheel speed shift This part replaces GW-2178. Price: $124.90 |
| 16 |
719-04015P |
Power Unit Transmission Cover This part replaces GW-2523. Price: $204.95 |
| 17 |
GW-1123 |
Gasket-transmission cover Price: $7.44 |
| 18 |
710-0376 |
Bolt-hex hd., 5/16-18 x 1", Grade 5, (remove with care) Price: $3.66 |
| 19 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 20 |
1901439 |
Spring-neutral plunger remove with care Price: $10.67 |
| 21 |
GW-1035 |
Plunger-neutral ( remove with care) Price: $33.23 |
| 22 |
1901440 |
Clip Ring-retains neutral pluger Price: $4.79 |
| 23 |
1186393 |
Nut-hex, flange locknut, 3/8" -16 Price: $2.63 |
| 24 |
1902004 |
Bolt-hex hd., 3/8-16 x 1-1/2", threaded full length Price: $7.46 |
| 25 |
786-04002 |
Lever-eccentric, tines/PTO clutch Price: $49.65 |
| 26 |
710-3013 |
Bolt-hex hd., 1/4-20 x 1/2" Price: $4.02 |
| 27 |
741-04008 |
Bushing-tines/PTO clutch lever eccentric shaft Price: $25.38 |
| 28 |
GW-9516 |
Retaining Ring-(snap ring), external Price: $3.56 |
| 29 |
GW-2461 |
Eccentric-shaft, tines/PTO clutch lever Price: $34.31 |
| 30 |
GW-9911 |
Lockwasher-hi-collar, 1/4" Price: $5.23 |
| 31 |
710-04354 |
Screw, 1/4-20 x.375 This part replaces GW-9672. Price: $3.38 |
| 33 |
716-0101 |
Retaining Ring-external Price: $3.37 |
| 34 |
718-04615 |
Dog Clutch This part replaces 1909139. Price: $46.92 |
| 35 |
GW-9301 |
Key-3/16 sq x 1" Price: $3.46 |
| 36 |
710-0157 |
HEX SCREW 5/16-24 x .75 This part replaces 1100004. Price: $3.90 |
| 37 |
736-04193 |
Washer, 396 x 1140 x 095, B&S This part replaces GW-9944. Price: $5.94 |
| 38 |
GW-2107 |
Pulley-transmission drive, cast iron Price: $127.93 |
| 39 |
GW-50027 |
Washer-flat, hardened shoulder 1-1/4" Price: $5.94 |
| 40 |
1186310 |
Bolt-hex hd., 1/4-20 x 3/4", front bearing cap Price: $3.11 |
| 42 |
718-04007 |
Cap-front bearing Price: $16.60 |
| 43 |
921-04044 |
Oil Seal, .750 x 125 This part replaces 721-04044. Price: $8.80 |
| 46 |
941-0107 |
Bearing, Tapered Roller (with race) This part replaces GW-1714. Price: $41.81 |
| 47 |
GW-2655 |
Shaft-main drive, power unit Price: $193.24 |
| 48 |
921-04030 |
Oil Seal, .75 x 1.783 This part replaces 721-04030. Price: $11.33 |
| 49 |
716-04102 |
Retaining Ring, Int This part replaces GW-9517. Price: $3.85 |
| 50 |
715-0121 |
Pin-roll (spirol), 1/4 x 2" Price: $5.95 |
| 51 |
718-04006 |
Plug-retaining, pinion bearing Price: $43.49 |
| 52 |
GW-9604 |
O-Ring-retaining plug Price: $4.62 |
| 54 |
GW-9404 |
Bearing-ball, pinion shaft Price: $24.30 |
| 55 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces GW-1126. Price: $4.37 |
| 56 |
GW-1222 |
Stem Pinion-slow speed gear & shaft Price: $122.90 |
| 57 |
716-04119 |
External Retaining Ring, 1.387 ID This part replaces GW-9502. Price: $12.96 |
| 58 |
GW-2656 |
Worm Gear-bronze, wheel drive Price: $129.55 |
| 59 |
GW-9300 |
Key-3/16" x 5/8" Price: $3.22 |
| 60 |
GW-1233 |
Gear-fast speed pinion Price: $125.18 |
| 61 |
921-04031 |
Oil Seal, 1.0 x 1.499 This part replaces 721-04031. Price: $9.58 |
| 62 |
716-04104 |
Retaining Ring This part replaces 1909950. Price: $3.85 |
| 64 |
941-04300 |
Bushing, 1.25 x 1 x .005 x 1.5 This part replaces GW-1086. Price: $15.25 |
| 65 |
753-05574 |
KIT-SERVICE WHEEL SHAFT 611-04025 Not Available This part replaces 911-04025. Price: |
| 66 |
714-04014 |
Key-Hi Pro, 1/4" x 1-3/4" Price: $18.36 |
| 67 |
GW-1223 |
Gear-slow spee, wheel drive Price: $196.25 |
| 68 |
GW-1232 |
Gear-fast speed, wheel drive Price: $135.63 |
| 69 |
GW-1237 |
Dog Clutch-wheel drive Price: $142.70 |
| 70 |
GW-1112 |
Pin-clutch guide, 1/4" diameter Price: $4.06 |
| 71 |
1911372 |
SPRING PIN .188X1. Not Available Price: |
| 72 |
619-04000-0637 |
Wheel Speed Shifting Lever This part replaces 619-04000. Price: $53.27 |
| 73 |
921-04034 |
Oil Seal, .625 x 1.0 This part replaces 721-04034. Price: $9.37 |
| 74 |
738-04448 |
PIN This part replaces GW-1442. Price: $7.14 |
| 75 |
611-04003 |
Eccentric Shaft-wheel speed shifting Price: $78.82 |
| 76 |
GW-1441 |
Spring-eccentric shift Price: $3.61 |
| 78 |
GW-2109099 |
HOUSING-POWER UNIT TRA This part replaces GW-2109. Price: $822.57 |
| 79 |
GW-9359 |
Pin-alignment Price: $3.22 |
| 80 |
1100067 |
HEX HEAD CAP SCREW Not Available Price: |
| 81 |
GW-9928 |
Washer-disc spring (concave), domed side faces bolt head Price: $11.23 |
| 82 |
GW-2126 |
Post-with threaded hole for Ref. No. 80 Price: $27.91 |
| 83 |
1105620 |
Plug-pipe, 1/4" Price: $3.66 |
| 84 |
GW-9122 |
Plug-red plastic, thread protector Price: $8.93 |
| 86 |
777I20944 |
LABEL-FORWARD INTR Not Available Price: |
