| Ref | Part Number | Description |
|---|
| 1 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 1 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 2 |
100-4939-03 |
CARRIER-SIDEWINDER Price: $1,133.42 |
| 2 |
539106883 |
WHEEL/TIRE.ASM.23X10.5-12.GREY Price: $279.99 |
| 3 |
32128-33 |
NUT-HF Price: $0.25 |
| 3 |
539101468 |
NUT 3/4-16 HEX SLTD GR5 ZD Price: $2.99 |
| 4 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 4 |
539977703 |
CLEVIS PIN 3/8 X 1 1/8 Price: $4.99 |
| 5 |
539102415 |
HUB W/BRAKE DRUM Price: $139.99 |
| 5 |
99-3433 |
WIRE-CENTER Price: $19.58 |
| 6 |
104-0416-0P |
BRACKET-SLIDE This part replaces 104-0416-03. Price: $89.86 |
| 6 |
539104288 |
PIN COTTER 4MM X 45MM Price: $2.99 |
| 7 |
104-0417 |
SLIDE-PLASTIC Price: $9.00 |
| 7 |
539104417 |
MB WHEEL MOTOR Price: $899.99 |
| 8 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 8 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 9 |
539102746 |
CLEVIS PIN Price: $2.99 |
| 9 |
95-8531 |
SHAFT-PIVOT, LIFTARM Price: $139.66 |
| 10 |
325-10 |
SCREW-HH Price: $1.82 |
| 10 |
539102817 |
COMPRESSION SPRING Price: $3.99 |
| 11 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 11 |
539102821 |
TRUNION PIN Price: $5.99 |
| 12 |
325-19 |
SCREW-HH Price: $2.57 |
| 12 |
539102822 |
BRAKE BAND Price: $37.99 |
| 13 |
104-4865 |
CAP-BEARING Price: $56.97 |
| 13 |
539106873 |
BRAKE BAND SUPPORT Price: $27.99 |
| 14 |
3218-5 |
NUT-JAM Price: $0.27 |
| 14 |
539106972 |
LINKAGE Price: $8.99 |
| 15 |
325-7 |
SCREW-HH Price: $1.53 |
| 15 |
539106989 |
MOTOR STANDOFF Price: $39.99 |
| 16 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 16 |
539106990 |
BRAKE WLDMNT Price: $40.99 |
| 17 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 17 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 18 |
596739901 |
Yoke This part replaces 539977465. Price: $27.99 |
| 18 |
99-3373 |
BAR-SUPPORT, SLIDE Price: $9.76 |
| 19 |
539990155 |
NUT 3/8F Price: $2.99 |
| 19 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 20 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 20 |
75-9590 |
SPACER-CYLINDER Price: $6.55 |
| 21 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 21 |
539108616 |
BRAKE LEVER WLDMT Price: $44.99 |
| 22 |
104-4820-03 |
BRACKET-STOP, CARRIER Price: $200.26 |
| 22 |
539106969 |
BRAKE CROSS SHAFT Price: $34.99 |
| 23 |
136-3419 |
RH LIFTARM ASM This part replaces 115-3462. Price: $243.79 |
| 23 |
539106971 |
LINKAGE - SHORT Price: $2.99 |
| 24 |
136-3417 |
LH LIFTARM ASM This part replaces 115-3461. Price: $243.79 |
| 24 |
539105036 |
GRIP, PARK BRAKE Price: $3.99 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
596581701 |
Washers This part replaces 539102843. Price: $2.99 |
| 26 |
105-7560 |
SHAFT-CU PIVOT Price: $73.74 |
| 26 |
596739901 |
Yoke This part replaces 539977465. Price: $27.99 |
| 27 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 27 |
539108619 |
BUSHING Price: $2.99 |
| 28 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 28 |
539990155 |
NUT 3/8F Price: $2.99 |
| 29 |
104-0472 |
ROD Price: $44.63 |
| 29 |
539102797 |
FLANGE BEARING Price: $9.99 |
| 30 |
325-14 |
SCREW-HH This part replaces 323-42. Price: $2.64 |
| 30 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 31 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 31 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 32 |
110-8793-03 |
STOP-DECK, RH Price: $37.69 |
| 32 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 33 |
110-8794-03 |
STOP-DECK, LH Price: $37.69 |
| 33 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 34 |
3269-11 |
RIVET-POP Price: $0.68 |
| 34 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 35 |
539106791 |
HEX BOLT 3/8 X 1" Price: $2.99 |
| 35 |
86-5350 |
BUMPER-RUBBER Price: $46.29 |
| 36 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 36 |
539103547 |
WASHER Price: $0.99 |
| 37 |
539990258 |
NUT HEX 1/2 Price: $3.99 |
| 38 |
110-8787 |
FRONT CARRIER FRAME ASM Price: $525.65 |
| 38 |
539990254 |
WASHER 1/2" SPLIT LOCK Price: $2.99 |
| 39 |
539990622 |
HCS 1/2C X 1 1/4 SERRATED HEAD Price: $3.99 |
| 39 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 40 |
104-4613 |
TUBE-LATCH Price: $7.38 |
| 40 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 41 |
104-4612 |
ROD-LATCH Price: $52.35 |
| 41 |
539101151 |
RETAINING RING, 7/8" Price: $1.99 |
| 42 |
104-4237 |
CLIP-ROD Price: $27.28 |
| 42 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 43 |
3290-271 |
RIVET-POP Price: $0.25 |
| 43 |
539105029 |
BRACKET Price: $8.99 |
| 44 |
104-4828-03 |
BRACKET-ACTUATOR Price: $21.55 |
| 44 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 45 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 46 |
32128-44 |
NUT Price: $2.69 |
| 46 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 47 |
104-4826-03 |
ACTUATOR-RH Price: $30.11 |
| 47 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 48 |
104-4827-03 |
ACTUATOR-LH Price: $28.51 |
| 48 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 49 |
104-4819-03 |
BRACKET-PIVOT, LH Price: $37.66 |
| 50 |
104-4825-03 |
BRACKET-PIVOT, RH Price: $37.66 |
| 51 |
323-11 |
SCREW-HH Price: $1.08 |
| 52 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 53 |
104-4821 |
SPRING-TORSION Price: $6.26 |
| 54 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 539105983 |
539105983 |
RIM 0 OFFSET 8.5" WIDE Price: $119.99 |
| 539107392 |
539106882 |
WHEEL/TIRE.ASM.23X8.5-12.GREY This part replaces 539107392. Price: $104.99 |
| 539107431 |
539107431 |
TIRE.TURF.MASTER.23X10.5-12 Price: $249.99 |
| 539107432 |
522905001 |
TIRE 23X8.5-12 This part replaces 539107432. Price: $299.99 |
| 539912234 |
539912234 |
VALVE STEM TR-412 Price: $3.99 |
