| Ref | Part Number | Description |
|---|
| 1 |
539100024 |
BELT, AUX BLADE Price: $37.99 |
| 1 |
76-2760 |
HOSE ASSEMBLY Price: $259.75 |
| 2 |
539101958 |
BELT - ENG/DECK 48 Price: $74.99 |
| 2 |
76-2750 |
HOSE ASSEMBLY Price: $277.12 |
| 3 |
237-58 |
O-RING Price: $2.18 |
| 3 |
539104562 |
BELT SHIELD 48" Price: $299.99 |
| 4 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 4 |
539102070 |
KNOB, THREE PRONG Price: $4.99 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 5 |
539102056 |
WASHER, 3/8 SEALING Price: $2.99 |
| 6 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 6 |
76-2770 |
HOSE ASM Price: $271.52 |
| 7 |
237-22 |
O-RING Price: $2.43 |
| 7 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 8 |
539990553 |
HCS 5/16 X 3 Price: $4.99 |
| 8 |
69-4320 |
FITTING-HYD, 90 DEG Price: $154.75 |
| 9 |
237-42 |
O-RING Price: $2.78 |
| 9 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
539102334 |
TAPBOLT 3/8C X 4 1/2 Price: $2.99 |
| 11 |
539976980 |
NUT 5/8F HEX Price: $2.99 |
| 11 |
94-4907 |
MOTOR-HYD This part replaces 69-2780. Price: $1,685.80 |
| 12 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 12 |
539102332 |
HCS 5/8F X 8 1/2 Price: $11.99 |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 13 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 14 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 14 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 15 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 15 |
539976436 |
BLADE SPACERS Price: $2.99 |
| 16 |
325-7 |
SCREW-HH Price: $1.53 |
| 16 |
539102245 |
SPACER Price: $8.99 |
| 17 |
539102675 |
MACHINERY BUSHING 10 GA. Price: $8.99 |
| 17 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 18 |
32108-103 |
SCREW-FH Price: $0.68 |
| 18 |
539107418 |
HOUSING ASM This part replaces 539102440. Price: $279.99 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
539102236 |
PAD Price: $22.99 |
| 20 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 20 |
539102320 |
TUBE CAP Price: $6.99 |
| 21 |
32120-72 |
RING-SNAP Price: $2.09 |
| 21 |
539130903 |
CHUTE, RUBBER DISCHARGE WB Price: $49.99 |
| 22 |
256-188 |
BUSHING Price: $5.70 |
| 22 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 23 |
539976398 |
PULLEY W/SETSCREWS Price: $49.99 |
| 23 |
69-6610-01 |
ARM-IDLER This part replaces 69-6610. Price: $84.61 |
| 24 |
325-8 |
SCREW-HH Price: $3.52 |
| 24 |
539101995 |
KEY 1/4 SQ X 1 1/8 Price: $2.99 |
| 25 |
539101819 |
PULLEY, DOUBLE W/SETS Price: $129.99 |
| 25 |
69-5430-03 |
PULLEY-IDLER, FLAT This part replaces 69-5430. Price: $63.15 |
| 26 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 26 |
69-6970 |
SPACER-IDLER, FLAT Price: $13.54 |
| 27 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 27 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 28 |
256-117 |
BUSHING Price: $4.07 |
| 28 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 29 |
3269-25 |
RIVET-POP Price: $0.27 |
| 29 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 30 |
539101979 |
ENGAGEMENT ARM Price: $54.99 |
| 30 |
69-6780 |
DISCONTINUED Price: Call Us |
| 31 |
539101836 |
BUSHING, SLEEVE Price: $2.99 |
| 31 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 32 |
539102031 |
BLADE ROD 48" Price: $13.99 |
| 32 |
69-6260 |
MAGNET Price: $58.32 |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 33 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 34 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 34 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 35 |
32128-23 |
NUT-HF Price: $1.51 |
| 35 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 36 |
539100075 |
SNUBBER Price: $32.99 |
| 36 |
76-1670-03 |
SPRING-EXTENSION This part replaces 76-1670. Price: $24.92 |
| 37 |
3217-9 |
NUT-HH Price: $0.37 |
| 37 |
539102656 |
SPACER Price: $3.99 |
| 38 |
596739801 |
PULLEYS This part replaces 539976688. Price: $29.99 |
| 38 |
69-6550 |
TENSIONER WA Price: $72.13 |
| 39 |
539101980 |
EYEBOLT PIVOT Price: $14.99 |
| 39 |
95-0833 |
DECAL-BELT ROUTING,CENTER This part replaces 82-2560. Price: $20.90 |
| 40 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 40 |
539101981 |
EYEBOLT, LH Price: $11.99 |
| 41 |
13-4969 |
FRONT DECK W/DECALS Price: $3,199.64 |
| 41 |
539101983 |
TURNBUCKLE Price: $11.99 |
| 42 |
3233-27 |
SCREW-CARR Price: $2.17 |
| 42 |
539101982 |
EYEBOLT, RH Price: $37.99 |
| 43 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 43 |
98-0755-03 |
PLATE - TENSIONER,ASM This part replaces 69-6490. Price: $74.44 |
| 44 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 44 |
77-2830 |
SPRING ROD Price: $85.37 |
| 45 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 45 |
539101978 |
ARM WELDMENT Price: $84.99 |
| 46 |
539101231 |
IDLER SPINDLE Price: $11.99 |
| 47 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 47 |
69-6890 |
DISCONTINUED Price: Call Us |
| 48 |
539102237 |
IDLER ARM, AUX. Price: $84.99 |
| 48 |
86-7480 |
COMPRESSION SPRING This part replaces 69-9270. Price: $35.91 |
| 49 |
539102337 |
TENSION ROD Price: $11.99 |
| 50 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 50 |
539976695 |
BUSHING, IDLER FLANGE Price: $7.99 |
| 51 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 51 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 52 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 52 |
69-6390 |
DISCONTINUED Price: Call Us |
| 53 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 53 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 54 |
539990449 |
NUT 7/16C HEX Price: $2.99 |
| 54 |
69-6790 |
RH CENTER COVER Price: $140.29 |
| 55 |
539976956 |
SET SCREW 5/16 NYLOC Price: $2.99 |
| 56 |
539104790 |
DECAL, HUSQVARNA 17.5" Price: $12.99 |
| 56 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 57 |
596435501 |
Bolts This part replaces 539102335. Price: $3.99 |
| 57 |
95-0817 |
DECAL-HOC This part replaces 69-0820. Price: $10.90 |
| 58 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 58 |
539104564 |
DECK W/DECALS 48" Price: $1,355.99 |
| 59 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 59 |
539105746 |
DECAL, EURO SEVERING Price: $2.99 |
| 60 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 61 |
539130916 |
PIVOT BRACKET - CHUTE Price: $32.99 |
| 62 |
539130922 |
BRKT, REINF-CHUTE WB Price: $34.99 |
| 63 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 64 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 65 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 66 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 67 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
