| Ref | Part Number | Description |
|---|
| 1 |
603000142 |
NUT, M8-1.25 HEX Price: $1.99 |
| 1 |
76-5070 |
OIL PUMP ASM Price: $729.22 |
| 2 |
603000579 |
SCREW, M8-125 X 22 HEX GR.8.8 Price: $2.99 |
| 2 |
94-3176 |
VALVE-RELIEF Price: $5.60 |
| 3 |
603000184 |
LOCKWASH Price: $1.99 |
| 3 |
76-5090 |
SPRING-PISTON Price: $4.54 |
| 4 |
603003083 |
GASKET, OHV EXHAUST Price: $11.99 |
| 4 |
94-3179 |
WASHER-SPRING Price: $1.50 |
| 5 |
603000270 |
BRACKET, MUFFLER MOUNTING Price: $24.99 |
| 5 |
76-5100 |
BOLT-SHOULDER Price: $5.63 |
| 6 |
603000431 |
CLAMP, 5" MUFFLER HOSE Price: $12.99 |
| 7 |
603003197 |
EXHAUST SYSTEM, FE290 Price: $449.99 |
| 7 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 8 |
603000065 |
WASHER, 5/16 TYPE A FLAT Price: $1.99 |
| 8 |
94-3124 |
SCREW-HH Price: $1.30 |
| 9 |
603000054 |
WASHER 1/4 FLAT Price: $1.99 |
| 9 |
94-3178 |
STRAINER Price: $99.33 |
| 10 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 10 |
77-3470 |
SCREW Price: $3.37 |
| 11 |
603000072 |
LOCKWASHER, 5/16 SPLIT Price: $1.99 |
| 11 |
77-3490 |
SCREW Price: $4.42 |
| 12 |
94-3177 |
PLUG Price: $7.38 |
