| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 1 |
576769202 |
DECK.SVC.W/DECALS.52.PZT.ORNGE Price: $1,799.99 |
| 2 |
576479802 |
BELT, "B" Price: $119.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 84-8500. Price: $107.85 |
| 3 |
539105712 |
BLADE - HEAVY DUTY 18" Price: $24.99 |
| 3 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 4 |
237-30 |
O-RING Price: $2.50 |
| 4 |
521969403 |
SHIELD BELT 52" RH ORANGE Price: $52.99 |
| 5 |
43-8610 |
GUIDE Price: $23.35 |
| 5 |
521969503 |
SHIELD.BELT.52".LH.ORANGE Price: $74.99 |
| 6 |
593565003 |
PLATE CONFINEMENT 52" PLATE.PN This part replaces 539112417. Price: $27.99 |
| 6 |
84-8520-01 |
BRACKET-SWITCH, PTO This part replaces 84-8520. Price: $11.07 |
| 7 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 7 |
539130901 |
CHUTE, RUBBER DISCHARGE 52/61" Price: $79.99 |
| 8 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 8 |
539112124 |
PULLEY, 52 Price: $39.99 |
| 9 |
43-3860 |
SHAFT-PIVOT, PTO Price: $55.10 |
| 9 |
510015102 |
Pulleys This part replaces 510015101. Price: $49.99 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 10 |
525598202 |
PULLEYS This part replaces 525598201. Price: $39.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 12 |
106-4383 |
BELT-V, BANDED This part replaces 53-9660. Price: $40.02 |
| 12 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 13 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 13 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 14 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 15 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 15 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 16 |
3219-7 |
NUT-HEX Price: $1.53 |
| 16 |
596840301 |
Shields This part replaces 510262201. Price: $19.99 |
| 17 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 17 |
525464402 |
IDLER.ARM.BLACK Price: $9.99 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 18 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 19 |
3-8812 |
SPACER-SPRING, ANCHOR Price: $15.47 |
| 19 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539131383. Price: $129.99 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
510264201 |
SPACER, IDLER BEARINGS Price: $5.99 |
| 21 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 21 |
525465601 |
SPACER, IDLER PIVOT Price: $8.99 |
| 22 |
525310901 |
SPRING, TORSION, IDLER Price: $84.99 |
| 22 |
92-5727 |
SCREW-LOCK, PATCH Price: $0.92 |
| 23 |
539112050 |
BEARING, BALL Price: $5.99 |
| 23 |
92-5723 |
BUSHING-FORK, PTO Price: $4.74 |
| 24 |
110-9681-03 |
FORK-PTO This part replaces 92-4060. Price: $195.34 |
| 24 |
510263701 |
BEARING, IDLER ARM Price: $5.99 |
| 25 |
27-7370 |
PTO BRAKE ASM Price: $218.20 |
| 25 |
522729701 |
BEARING, IDLER PIVOT Price: $7.99 |
| 26 |
577073401 |
BEARING, IDLER STANDOFF Price: $11.99 |
| 26 |
93-3769 |
PIN-CLEVIS Price: $4.14 |
| 27 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 27 |
574262102 |
BELT.GUIDE.BLACK Price: $29.99 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 28 |
574262202 |
Belt Keepers This part replaces 574262201. Price: $5.99 |
| 29 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 29 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 30 |
539130917 |
PIVOT BRACKET - CHUTE Price: $129.99 |
| 30 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 31 |
100-6599 |
PTO PIVOT ASM This part replaces 43-5500. Price: $780.32 |
| 31 |
576388702 |
BRACKET, SPRING STOP Price: $24.99 |
| 32 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 32 |
592964402 |
BRACKET.REINF.CHUTE.52/61.EDIP This part replaces 539130920. Price: $22.99 |
| 33 |
3219-3 |
NUT-HEX Price: $0.34 |
| 33 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 34 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 34 |
596319701 |
Washers This part replaces 539916561. Price: $1.99 |
| 35 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 35 |
574202002 |
Hardware This part replaces 574202001. Price: $4.99 |
| 36 |
3256-41 |
WASHER Price: $1.18 |
| 36 |
539108366 |
HCS 1/2-13 X 4 GR 5 ZD Price: $5.99 |
| 37 |
5-0652 |
SPACER Price: $5.35 |
| 37 |
596435401 |
Bolts This part replaces 539101686. Price: $1.99 |
| 38 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 38 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 39 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 39 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 40 |
251-252 |
BEARING Price: $98.35 |
| 40 |
596337801 |
Bolts This part replaces 539128101. Price: $4.99 |
| 41 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 41 |
577117702 |
Hardware This part replaces 577117701. Price: $3.99 |
| 42 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 42 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 43 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 43 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 44 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 45 |
596435701 |
Bolts This part replaces 539107271. Price: $2.99 |
| 46 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 46 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 47 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 47 |
596433401 |
Nuts This part replaces 539990625. Price: $2.99 |
| 48 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 48 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 49 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 49 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 50 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 50 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 51 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 51 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 52 |
5-0701 |
ANCHOR Price: $4.07 |
| 52 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 53 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 53 |
596565001 |
Washers This part replaces 539109600. Price: $2.99 |
| 54 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 54 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 55 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 55 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 56 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 56 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 66 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 67 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 68 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 69 |
237-7 |
O-RING Price: $8.82 |
| 70 |
218-461 |
NUT-HH Price: $2.50 |
| 71 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 72 |
321-4 |
SCREW-HH Price: $0.99 |
| 73 |
86-7050 |
BRACKET-SWITCH, ACTUATOR Price: $16.28 |
| 74 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 75 |
79-9890 |
Washer-Shim Price: Call Us |
