| Ref | Part Number | Description |
|---|
| 1 |
140-2558-03 |
GTX SWING ARM ASM [BLACK] This part replaces 131-8520-03. Price: $731.40 |
| 2 |
131-8503-03 |
BRACKET-STARTER/GENERATOR Price: $37.43 |
| 3 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
131-8444 |
STARTER/GENERATOR ASM Price: $426.18 |
| 6 |
65-8270 |
WASHER Price: $1.22 |
| 7 |
119-4036 |
SCREW-HHF Price: $0.53 |
| 8 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 9 |
121-6277 |
PULLEY-DRIVE Price: $28.48 |
| 10 |
119-6011 |
SECONDARY CLUTCH ASM Price: $617.73 |
| 11 |
104-6563 |
WASHER-STEPPED Price: $9.44 |
| 12 |
119-0723 |
SCREW-HH, LOCK Price: $8.62 |
| 13 |
131-8329 |
BRACKET-MUFFLER Price: $7.98 |
| 14 |
70-8470 |
SCREW-HH Price: $1.76 |
| 15 |
145-2507 |
ENGINE-KOHLER CH440 This part replaces 131-8502. Price: $1,200.96 |
| 16 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 17 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 18 |
131-8510 |
MANIFOLD-EXHAUST Price: $47.88 |
| 19 |
131-8332 |
PIPE-INTERMEDIATE Price: $42.25 |
| 20 |
131-8334 |
MUFFLER Price: $226.99 |
| 21 |
104-6478 |
SPRING-EXTENSION Price: $13.02 |
| 22 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 23 |
3234-39 |
SCREW-HHF Price: $1.09 |
| 24 |
140-4648 |
PLATE-SPANNER This part replaces 131-8501-03. Price: $43.14 |
| 25 |
139-3392 |
SCREW-LOCK This part replaces 95-4184. Price: $1.49 |
| 26 |
32180-030 |
CLIP-TIE Price: $4.19 |
| 27 |
95-5806 |
BRACKET-MOUNTING Price: $28.01 |
| 28 |
99-7120 |
AIR CLEANER ASM Price: $118.01 |
| 29 |
136-7859 |
RAIN CAP KIT Price: $23.88 |
| 30 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 31 |
131-8489 |
HOSE-INTAKE, AIR Price: $58.25 |
| 32 |
2412-111 |
CLAMP Price: $4.39 |
| 33 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 34 |
138-0095 |
PRIMARY CLUTCH ASM Price: $590.09 |
| 35 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 36 |
131-8521 |
SCREW-HH Price: $5.63 |
| 37 |
131-8567 |
BELT-VARIABLE Price: $89.84 |
| 38 |
94-8803 |
V-BELT, IMPELLER Price: $22.99 |
| 39 |
131-8505 |
BRACKET-THROTTLE Price: $24.99 |
| 40 |
131-8524 |
BUSHING-FLANGE Price: $12.08 |
| 41 |
131-8504 |
LEVER-THROTTLE Price: $9.97 |
| 42 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 43 |
110-2619 |
KEEPER-SPRING Price: $6.44 |
| 44 |
99-7847 |
BALL-STUD Price: $30.99 |
| 45 |
71-5470 |
SPRING-BRAKE Price: $3.59 |
| 47 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 48 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 49 |
2412-105 |
CLAMP-TUBE, DOUBLE Price: $2.26 |
| 50 |
127-8860 |
CABLE-ACCELERATOR Price: $91.86 |
| 51 |
131-8540 |
CABLE-CHOKE Price: $48.95 |
