| Ref | Part Number | Description |
|---|
| 1 |
710-05316 |
Bolt, M6x22 Price: $3.56 |
| 1 |
74760524 |
Bolt, Hex Head, Gr. 25/16-18 x 1-1/2 Price: Call Us |
| 2 |
74780652 |
Bolt, Hex Head, 3/8-16 x 3-1/4 Price: Call Us |
| 2 |
951-15352 |
Valve Cover Price: $17.52 |
| 3 |
19131311 |
Washer, 3/32 x 13/16 x 11 Price: Call Us |
| 3 |
951-15576 |
Gasket, Valve Cover Price: $8.76 |
| 4 |
951-11981A |
ROCKER ARM ASSEMBLY This part replaces 951-15353. Price: $35.16 |
| 5 |
73900600 |
Nut, Hex, Flangelock 3/8-16 Price: Call Us |
| 5 |
951-12269 |
Valve Adjust Cap, Exhaust Price: $5.48 |
| 6 |
9057R428 |
Shield, Tine Price: Call Us |
| 6 |
951-14911A |
VALVE SPRING SEAT This part replaces 951-14911. Price: $4.64 |
| 7 |
188195 |
Bracket, Engine, R.H. Price: Call Us |
| 7 |
951-15356 |
Valve Spring Price: $4.91 |
| 8 |
165834 |
Bracket, Engine, L.H. Price: Call Us |
| 8 |
951-12077A |
VALVE SPRING RETAINER This part replaces 951-12077. Price: $3.49 |
| 9 |
951-15373 |
Intake Vavle Price: $18.44 |
| 10 |
710-06507 |
Bolt, M10x1.25x87 Price: $6.24 |
| 10 |
73970500 |
Nut, Hex, Flangelock Price: Call Us |
| 11 |
187912 |
Bolt, Shoulder Price: Call Us |
| 11 |
951-11965B |
PUSH ROD GUIDE This part replaces 951-11965A. Price: $5.75 |
| 12 |
151222 |
Transmission Price: Call Us |
| 12 |
951-14912A |
VALVE CAP This part replaces 951-14912. Price: $3.03 |
| 13 |
951-11964A |
INTAKE VALVE SEAL This part replaces 951-11964. Price: $9.96 |
| 14 |
9173R |
Spacer, Split Price: Call Us |
| 14 |
951-15374 |
Exhaust Valve Price: $21.94 |
| 15 |
710-06593 |
HEX HEAD BOLT M8X16 Not Available Price: |
| 16 |
19091412 |
Washer, 9/32 x 7/8 x 12 Ga. Price: Call Us |
| 16 |
907-06699 |
Lift Hook Price: $11.56 |
| 17 |
19092016 |
Washer, 9/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 17 |
710-04915 |
Bolt, M6x12 Price: $3.82 |
| 18 |
10040400 |
Washer, Lock 1/4 Price: Call Us |
| 18 |
710-04914 |
Bolt, M6x10 Price: $3.71 |
| 19 |
710-06604 |
HEX HEAD SCREW M6X10 Not Available Price: |
| 20 |
907-06783 |
Shroud, Right Price: $9.84 |
| 21 |
907-06597 |
CYLINDER SHROUD - LH Not Available Price: |
| 22 |
951-15645 |
Support Clamp Price: $3.25 |
| 23 |
951-15585 |
Regulator Price: $87.80 |
| 24 |
712-05015 |
Nut, M6 Price: $5.78 |
| 25 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 26 |
951-15372 |
CYLINDER HEAD - LH Not Available Price: |
| 27 |
710-06506 |
Bolt, M8x20 Price: $4.26 |
| 28 |
907-06675 |
REAR LIFT BRACKET Price: $5.64 |
| 29 |
710-04911 |
Stud, M8x34 Price: $3.65 |
| 30 |
907-06570 |
Cylinder Head Shroud Price: $7.17 |
| 31 |
715-04097 |
Pin, 12x20 Price: $5.34 |
| 32 |
921-04912 |
Cylinder Head Gasket LH Price: $13.13 |
| 33 |
951-15355 |
Push Rod Price: $5.78 |
| 34 |
951-05422 |
Piston Ring Set Price: $24.21 |
| 35 |
951-11632 |
PISTON PIN SNAP RING Price: $3.53 |
| 36 |
911-06733 |
Piston Pin Price: $5.90 |
| 37 |
951-15385 |
Piston Price: $40.38 |
| 38 |
951-05376 |
Connecting Rod Assembly Price: $109.76 |
| 39 |
951-15587 |
Connecting Rod Bearing Price: $12.96 |
| 40 |
710-06605 |
HEX HEAD BOLT M14-1.5X1.5 Not Available Price: |
| 41 |
736-05220 |
FLAT WASHER 14X1.5X22 Not Available Price: |
| 42 |
710-06522 |
Bolt, M8x110 Price: $4.09 |
| 43 |
907-06785 |
STARTER SOLENOID BRACKET Price: $8.93 |
| 44 |
925-06907 |
Electric Starter Price: $403.28 |
| 45 |
915-05026 |
Pin, 10x12 Price: $4.40 |
| 46 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 47 |
736-05109 |
Washer Price: $5.34 |
| 48 |
710-06569 |
PANHEAD SCREW ST5.5X25 Not Available Price: |
| 49 |
951-12205 |
Shroud Price: $9.07 |
| 50 |
931-05427 |
Air Filter Assembly Price: $18.44 |
| 51 |
937-05075 |
Air Filter Assembly Price: $25.43 |
| 52 |
931-05532 |
Cylinder Head Baffle Price: $70.24 |
| 53 |
710-06496 |
Stud, M6x117 Price: $6.06 |
| 54 |
710-06486 |
Stud, M6x117 Price: $5.81 |
| 55 |
912-05102 |
Nut, M20x1.5 Price: $7.35 |
| 56 |
936-05110 |
Washer, 20.5x5x40 Price: $5.34 |
| 57 |
951-15370 |
Cooling Fan Plate Price: $8.76 |
| 58 |
931-11868 |
Cooling Fan Not Available Price: |
| 60 |
937-05067 |
Oil Seal, 38x58x8 Price: $13.55 |
| 61 |
951-15386 |
Trigger Support Price: $5.81 |
| 62 |
951-15204 |
Trigger Price: $21.54 |
| 63 |
710-06517 |
SCREW - M5-0.8X12 PANHEAD Not Available Price: |
| 64 |
951-15387 |
Ignition Coil Price: $140.49 |
| 65 |
710-06516 |
HEX HEAD FLANGE BOLT M5-0.8X20 Not Available Price: |
| 66 |
710-04943 |
Bolt, M6x28 Price: $3.76 |
| 67 |
951-15402 |
BREATHER COVER Not Available Price: |
| 68 |
951-15397 |
BREATHER GASKET Not Available Price: |
| 69 |
951-15399 |
Oil Block Price: $5.35 |
| 70 |
951-15398 |
Breather Reed Price: $5.25 |
| 71 |
710-04969 |
Bolt, M6x30 Price: $3.66 |
| 72 |
951-15586 |
Charging Coil Price: $87.72 |
| 73 |
725-06031 |
Tape, L=150mm Price: $2.04 |
| 74 |
925-06895 |
Cable Assembly Price: $87.72 |
| 75 |
951-15437 |
Harness Support Bracket Price: $4.17 |
| 76 |
710-04968 |
Bolt, M6x16 Price: $5.77 |
| 77 |
710-06292 |
Bolt, M6x22 Price: $4.40 |
| 78 |
951-15401 |
Breather Filter Screen Price: $5.25 |
| 79 |
951-15396 |
CRANKCASE Not Available Price: |
| 80 |
736-05221 |
WASHER 20.5X1.5X18 Not Available Price: |
| 81 |
710-06607 |
HEX HEAD BOLT M10X1X10 Not Available Price: |
| 82 |
951-15213 |
Temperature Sensor Price: $32.86 |
| 83 |
951-15212 |
Temperature Sensor Clip Price: $6.01 |
| 84 |
921-04913 |
Cylinder Head Gasket - Rh Price: $13.13 |
| 85 |
951-15371 |
Cylinder Head Price: $202.50 |
| 86 |
907-06601 |
Shroud, Left Price: $4.88 |
| 87 |
907-06596 |
Cylinder Head Baffle Price: $18.77 |
| 88 |
951-15460 |
Mounting Bracket Price: $6.24 |
| 89 |
932-05473 |
Idle Spring Price: $7.02 |
| 90 |
951-15332 |
Choke Lever Price: $5.78 |
| 91 |
932-05531 |
Governor Spring Price: $7.54 |
| 92 |
932-05532 |
Governor Spring Price: $7.18 |
| 93 |
951-15404 |
Breather Hose Price: $10.35 |
| 94 |
951-12328 |
Intake Manifold Jacket Price: $3.49 |
| 95 |
951-15625 |
Intake Manifold Jacket Price: $5.70 |
| 96 |
931-12823 |
Throttle Link Clip Price: $4.47 |
| 97 |
951-05310A |
THROTTLE BODY This part replaces 951-05310. Price: $561.15 |
| 98 |
921-04880 |
Oil Sprayer Valve Cover Price: $5.95 |
| 99 |
710-06505 |
SCREW - M8X50 Not Available Price: |
| 100 |
921-04914 |
Gasket, Intake Manifold Price: $8.76 |
| 101 |
951-15403 |
Governor Gear Shaft Price: $12.27 |
| 102 |
736-05188 |
Washer, 8.5x2x15.8 Price: $2.73 |
| 103 |
941-05216 |
Bearing, HK081210 Price: $7.99 |
| 104 |
714-04077 |
Cotter Pin Price: $5.30 |
| 105 |
951-12388 |
Oil Seal, 8x14x4 Price: $3.69 |
| 106 |
951-15331 |
Governor Lever Price: $8.76 |
| 107 |
951-05380 |
Governor Gear Bracket Assembly Price: $25.26 |
| 108 |
919-05175 |
INTAKE MANIFOLD 9Q78 Not Available Price: |
| 109 |
710-06591 |
Stud - M6X35 Price: $3.58 |
| 110 |
710-06592 |
Stud - M6X46 Price: $4.26 |
| 111 |
951-15384 |
Lower Rocker Arm Price: $79.54 |
| 112 |
715-05064 |
Pin, 8x12 Price: $3.33 |
| 113 |
710-04919 |
Bolt, M6x25 Price: $3.86 |
| 114 |
921-04887 |
Gasket, Crankcase Price: $20.90 |
| 115 |
951-15366 |
Crankshaft Price: $377.43 |
| 116 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 117 |
736-05187 |
Washer, 38.5x1x54 Price: $3.71 |
| 118 |
941-05213 |
Bearing, 6003-Z Price: $9.78 |
| 119 |
951-15375 |
Camshaft Price: $157.36 |
| 120 |
951-05379 |
Governor Gear Price: $18.44 |
| 121 |
710-05003A |
BOLT M6-1 x 18 This part replaces 710-05003. Price: $3.11 |
| 122 |
951-05449 |
Oil Pump Price: $68.93 |
| 123 |
921-04916 |
Gasket, Oil Pump Price: $5.60 |
| 124 |
715-04088A |
DOWEL PIN This part replaces 715-04088. Price: $2.97 |
| 125 |
932-05534 |
Oil Pump Spring Price: $4.49 |
| 126 |
951-15588 |
Steel Ball, 9.5 Price: $3.50 |
| 127 |
951-15383 |
Filter Screw Price: $10.52 |
| 128 |
736-05199 |
Washer, 17.4x1x25.9 Price: $3.58 |
| 129 |
951-15589 |
O-Ring, 13.2x2.65 Price: $3.50 |
| 130 |
951-15590 |
Pin Price: $3.25 |
| 131 |
951-05450B |
DIPSTICK This part replaces 951-05450. Price: $29.58 |
| 132 |
710-05234 |
Bolt, M6x55 Price: $5.38 |
| 133 |
951-12690 |
Oil Filter This part replaces 951-15362. Price: $15.89 |
| 134 |
951-12253 |
Connection Pipe Price: $6.87 |
| 135 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 136 |
951-15360 |
Crankcase Cover Price: $87.65 |
