| Ref | Part Number | Description |
|---|
| 1 |
575885703 |
SCREW Price: $2.99 |
| 2 |
597909701 |
DAMPNER This part replaces 503869301. Price: $5.99 |
| 4 |
582285201 |
CARBURETTOR AREA BASE ASSY Price: $11.99 |
| 5 |
522620003 |
TANK CAP ASSY Price: $8.99 |
| 6 |
503578901 |
TANK LOCK Price: $4.99 |
| 7 |
589241101 |
SEALING Price: $4.99 |
| 8 |
503894703 |
CLIP GRAY Price: $9.99 |
| 9 |
595897705 |
CRANKCASE KIT This part replaces 595897702. Price: $279.99 |
| 10 |
112-7018 |
VALVE-INLET This part replaces 120-2563. Price: $41.87 |
| 10 |
503751801 |
PIN Price: $3.99 |
| 11 |
596351401 |
CATCH KIT SPARE PART Price: $14.99 |
| 12 |
596351302 |
SPIKE KIT This part replaces 596351301. Price: $6.99 |
| 13 |
575793501 |
SCREW ITXPANM M5X16 T27 10.9 Price: $3.99 |
| 14 |
581559201 |
GROMMET Price: $5.99 |
| 15 |
503212813 |
SCREW This part replaces 525887401. Price: $2.99 |
| 16 |
525798103 |
SCREW Price: $2.99 |
| 17 |
537377902 |
CHAIN CATCHER Price: $6.99 |
| 18 |
589721901 |
CHAIN GUIDE PLATE Price: $8.99 |
| 19 |
537403502 |
SINTERED BRONZE FILTER This part replaces 537403501. Price: $2.99 |
| 20 |
120-2564 |
VALVE-EXHAUST Price: $34.21 |
| 20 |
530026119 |
VALVE-CHECK (DUCKBILL) Price: $4.99 |
| 21 |
505125801 |
DEFLECTION LIMITER Price: $5.99 |
| 22 |
505217301 |
BAR BOLT Price: $4.99 |
| 23 |
720126952 |
PARALLEL PIN Price: $5.99 |
| 24 |
598857501 |
SLEEVE 12.2X 6.5X 7.4 This part replaces 589331301. Price: $4.99 |
| 25 |
503215325 |
SCREW Price: $3.99 |
| 26 |
582285901 |
AIR NOZZLE Price: $5.99 |
| 27 |
526818101 |
SCREW ITXSCM M4X15 T27 12.9 T Price: $2.99 |
| 28 |
525824401 |
SCREW ITXSCM WASHER M5X12 T27 Price: $2.99 |
| 29 |
593806001 |
GUIDE BUSHING This part replaces 501270802. Price: $4.99 |
| 30 |
595897601 |
GASKET KIT MARK II Price: $14.99 |
| 30 |
98-9648 |
SPRING-VALVE Price: $13.49 |
| 31 |
596911301 |
CAPS Price: $3.99 |
| 40 |
107-9092 |
RETAINER-SPRING Price: $2.58 |
| 50 |
117-7572 |
COLLET-SPRING, VALVE Price: $9.43 |
| 60 |
99-8385 |
SEAL-STEM, VALVE Price: $7.29 |
| 70 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 80 |
105-3790 |
R-ARM SHAFT ASM Price: $28.61 |
| 90 |
100-1762 |
BOLT This part replaces 100-9265. Price: $1.68 |
| 100 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 110 |
98-9506 |
STUD Price: $5.98 |
| 120 |
98-9393 |
NUT Price: $2.72 |
| 130 |
98-9385 |
WASHER-FLAT Price: $1.24 |
| 140 |
105-3758 |
PIN-SPRING Price: $0.57 |
| 150 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 160 |
110-3832 |
WASHER-PLAIN Price: $0.71 |
| 170 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 190 |
112-7020 |
ROCKER ARM ASM Price: $75.86 |
| 200 |
98-9502 |
SCREW-ADJUSTING Price: $2.78 |
