| Ref | Part Number | Description |
|---|
| 1 |
105-9861 |
STEERING CYLINDER ASM Price: $1,317.06 |
| 1 |
532190196 |
THROTTLE CONTROL Price: $32.99 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 5 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 5 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 6 |
32120-76 |
RING-SNAP, EXT Price: $0.34 |
| 7 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 8 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 10 |
106-9888 |
WASHER-FLAT Price: $0.49 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532162797. Price: $11.99 |
| 11 |
121-3101 |
MOTOR-PISTON Price: $2,639.96 |
| 12 |
237-166 |
O-RING Price: $10.46 |
| 13 |
104-0755 |
PINION-27 TOOTH Price: $168.40 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
100-3053 |
GEAR-45 TOOTH Price: $220.85 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 17 |
93-5268 |
NUT-LUG Price: $2.20 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 21 |
32136-14 |
NUT-HST Price: $3.38 |
| 22 |
92-5836 |
WASHER Price: $5.34 |
| 23 |
110-4750 |
DRIVE AXLE ASM Price: $8,909.28 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 25 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 25 |
532190784 |
THROTTLE CONTROL This part replaces 532191964. Price: $22.99 |
| 26 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 27 |
115-9142 |
PIN-REAR AXLE Price: $103.95 |
| 28 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 30 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 31 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 32 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
33114-025 |
SCREW-HH Price: $0.70 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 36 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 37 |
104-2353 |
PIN-DOWEL Price: $2.17 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 39 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 40 |
110-8829 |
SENDER-TEMPERATURE Price: $80.84 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
