| Ref | Part Number | Description |
|---|
| 1 |
603-0813A |
Pivot Bracket Assembly This part replaces 603-0813. Price: Call Us |
| 1 |
94-3622 |
HOOD ASM Price: $1,217.09 |
| 2 |
603-0862 |
VALVE CONTROL HANDLE Not Available Price: |
| 2 |
62-7400 |
DECAL Price: $24.54 |
| 3 |
32128-20 |
NUT-HF Price: $0.99 |
| 3 |
703-3598-0637 |
VALVE MOUNTING BRACKET Not Available Price: |
| 4 |
3230-27 |
SCREW-CARR Price: $0.75 |
| 4 |
703-3972-0637 |
PLATE-HYD FTG MTG (POWDER BLACK) Not Available Price: |
| 5 |
703-3973-0637 |
FITTING MOUNTING PLATE Not Available Price: |
| 5 |
76-2260 |
PAD-FOOTREST Price: $8.40 |
| 6 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 6 |
710-0501 |
Hex Screw, 1/4-20, 2.00, Gr5 Price: $6.24 |
| 7 |
710-0599 |
Hex Wash. Hd. Tapp Screw 1/4-20 x .50 Price: $3.86 |
| 7 |
76-2200-03 |
FOOTREST-PEDAL, TRACTION This part replaces 76-2200. Price: $42.73 |
| 8 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 8 |
710-0604A |
Hex Wash. Hd. Tapp Screw 5/16-18 x .625 Price: $3.96 |
| 9 |
710-1260A |
Hex Wash. Hd. Tapp Screw 5/16-18 x .75 Price: $3.34 |
| 9 |
93-6779-03 |
FOOTREST-RH This part replaces 93-6779. Price: $85.60 |
| 10 |
32128-33 |
NUT-HF Price: $0.25 |
| 10 |
711-1611 |
VALVE PIVOT SHAFT Not Available Price: |
| 11 |
711-1624A |
VALVE LINK Not Available This part replaces 711-1624. Price: |
| 11 |
93-6778-01 |
FENDER-RH This part replaces 93-6778. Price: $334.53 |
| 12 |
32128-44 |
NUT Price: $2.69 |
| 12 |
711-1637 |
Ball Joint Pivot Stud Price: $29.03 |
| 13 |
32148-7 |
NUT-CLINCH Price: $0.98 |
| 13 |
711-1642 |
CLEVIS PIN .199X.8125 Not Available Price: |
| 14 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 14 |
712-0256 |
HEX JAM NUT 5/16-24 Not Available Price: |
| 15 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 15 |
712-0324 |
Hex Lock Nut, 1/4-20, Gr8, Nylon Price: $3.38 |
| 16 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 16 |
93-6858-01 |
SHIELD-FRONT, RH This part replaces 93-6858. Price: $23.11 |
| 17 |
714-0104 |
Internal Cotter Pin Price: $3.90 |
| 17 |
93-6780-03 |
HINGE ASM This part replaces 93-6780. Price: $51.74 |
| 18 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 18 |
716-0865 |
Snap Ring, .5 Price: $3.86 |
| 19 |
256-320 |
BUSHING-NYLON Price: $7.44 |
| 19 |
918-3138 |
AUXILIARY PUMP Not Available This part replaces 718-3138. Price: |
| 20 |
718-3140 |
HYDRO CONTROL VALVE Not Available Price: |
| 20 |
93-6742-03 |
BRACKET-HOOD, PIVOT This part replaces 93-6742. Price: $12.30 |
| 21 |
3217-6 |
NUT-HEX Price: $1.19 |
| 21 |
723-0488 |
BALL JOINT ROD END Not Available Price: |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
727-3012 |
Fitting, 90° 6-6 Orb Price: $23.35 |
| 23 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 23 |
727-3206 |
AUX PUMP SUCTION TUBE Not Available Price: |
| 24 |
727-3210 |
HYDRO BUCKET TUBE Not Available Price: |
| 24 |
83-8510-01 |
BRACKET-FENDER, LEFT This part replaces 83-8510. Price: $24.64 |
| 25 |
727-3211 |
HYDRO BUCKET TUBE Not Available Price: |
| 25 |
83-9800-01 |
GRASS SHIELD-FRONT, LH This part replaces 83-9800. Price: $28.36 |
| 26 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 26 |
727-3212 |
HYDRO BOOM LIFT TUBE Not Available Price: |
| 27 |
727-3213 |
HYDRO BOOM LOWER TUBE Not Available Price: |
| 27 |
93-6776-01 |
FENDER-LH This part replaces 93-6776. Price: $317.84 |
| 28 |
727-3224 |
HYDRO COUPLER 3/8-18 MALE Not Available Price: |
| 28 |
84-1650 |
DECAL - BRAKE Price: $7.02 |
| 29 |
727-3225 |
Coupling, Female Hydr. 3/8-18 Price: $78.52 |
| 29 |
83-9710-03 |
FOOTREST-PEDAL, TRACTION This part replaces 83-9710. Price: $78.54 |
| 30 |
727-3226 |
AUX PUMP PRESSURE TUBE Not Available Price: |
| 30 |
83-9840 |
PAD-FOOT Price: $60.60 |
| 31 |
322-3 |
SCREW-HH Price: $0.79 |
| 31 |
727-3227 |
ACCESSORY PRESSURE TUBE Not Available Price: |
| 32 |
727-3228 |
HYDRO VALVE RETURN TUBE Not Available Price: |
| 32 |
93-6927 |
DISCONTINUED Price: Call Us |
| 33 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 33 |
727-3229 |
HYDRO VALVE RETURN TUBE Not Available Price: |
| 34 |
727-3261 |
FEMALE COUPLER PLUG Not Available Price: |
| 35 |
727-3262 |
MALE COUPLER CAP Not Available Price: |
| 36 |
731-3353 |
CONTROL KNOB HANDLE Not Available Price: |
| 37 |
731-3374 |
RED INDICATOR WASHER Not Available Price: |
| 38 |
731-3375 |
YELLOW INDICATOR WASHER Not Available Price: |
| 39 |
731-3376 |
GREEN INDICATOR WASHER Not Available Price: |
| 40 |
731-3377 |
BLUE INDICATOR WASHER Not Available Price: |
| 41 |
735-0696 |
CONTROL HANDLE BOOT Not Available Price: |
| 43 |
737-3112 |
HYDRO FITTING Not Available Price: |
| 44 |
737-3113 |
HYDRO FITTING Not Available Price: |
| 45 |
737-3125 |
HYDRO FITTING Not Available Price: |
| 46 |
737-3129 |
BULKHEAD MALE FITTING Not Available Price: |
| 47 |
737-3130 |
BULKHEAD MALE FITTING Not Available Price: |
| 503203425 |
525887001 |
SCREW CITXPANMO This part replaces 503203425. Price: $3.99 |
| 503910501 |
503910501 |
CYLINDER COVER Price: $37.99 |
