| Ref | Part Number | Description |
|---|
| 1 |
51-7740 |
STOPPER SET Price: $15.31 |
| 2 |
51-7730 |
PINION SET Price: $89.08 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
51-7600 |
SCREW SET Price: $16.49 |
| 5 |
51-7610 |
DISCONTINUED Price: Call Us |
| 6 |
51-7620 |
DISCONTINUED Price: Call Us |
| 7 |
51-7640 |
LEVER ASM Price: $49.23 |
| 8 |
51-7650 |
SPRING SET Price: $25.07 |
| 9 |
51-7660 |
BRACKET ASM Price: $188.94 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
51-7670 |
SWITCH ASM Price: $506.66 |
| 11 |
51-7690 |
DISCONTINUED Price: Call Us |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 12 |
51-7680 |
ARMATURE SET Price: $932.81 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
107-4398 |
BEARING This part replaces 51-7700. Price: $45.79 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 14 |
93-3687tn |
Bolt Set Price: Call Us |
| 15 |
51-7840 |
RUBBER RING Price: $4.27 |
| 15 |
529999002 |
TANK ASSY W/CAP 4 GAL REAR EPA This part replaces 532438082. Price: $249.99 |
| 16 |
51-7830 |
BRACKET Price: $58.39 |
| 17 |
51-7810 |
BRUSH HOLDER Price: $90.99 |
| 18 |
51-7820 |
SPRING Price: $3.97 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
51-7800 |
YOKE ASM Price: $401.60 |
| 20 |
51-7790 |
PACKING Price: $14.14 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 21 |
51-7780 |
COVER SET Price: $28.34 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
51-7770 |
GEAR Price: $57.77 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
51-7760 |
SHAFT ASM Price: $599.61 |
| 24 |
51-7630 |
OIL SEAL Price: $43.26 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 This part replaces 532424765. Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 This part replaces 532424766. Price: $24.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
