| Ref | Part Number | Description |
|---|
| 1 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 2 |
104-7704 |
SPRING-LATCH, BRAKE Price: $12.68 |
| 4 |
125-5155-01 |
FRAME ASM This part replaces 107-9543-01. Price: $3,821.35 |
| 5 |
93-8062 |
DECAL-BRAKE, PARKING Price: $4.95 |
| 6 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 7 |
114-8414 |
SCREW-HHF Price: $1.97 |
| 8 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 9 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 10 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 11 |
104-2096 |
BRACKET-SWITCH Price: $35.42 |
| 12 |
104-7703 |
HINGE-LOWER Price: $22.15 |
| 13 |
104-2094 |
BRAKE-LATCH Price: $150.10 |
| 14 |
104-7702 |
PLATE-SWITCH Price: $16.15 |
| 15 |
83-1700 |
BUSHING-FLANGE Price: $7.80 |
| 16 |
93-2073-01 |
SHIELD-WHEEL, LH Price: $104.03 |
| 17 |
93-2072-01 |
SHIELD-WHEEL, RH Price: $92.07 |
| 18 |
283-61 |
PIN-YOKE Price: $1.56 |
| 20 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 21 |
93-2075-01 |
BRAKE PEDAL ASM Price: $188.33 |
| 22 |
93-7629 |
PAD-FOOT, BRAKE Price: $25.13 |
| 23 |
283-87 |
PIN-CLEVIS Price: $8.89 |
| 24 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 25 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 26 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 27 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 28 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 29 |
104-2057 |
SENSOR Price: $136.35 |
