| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
76-9970 |
FOUR WHEEL DRIVE VALVE ASM Price: $1,652.64 |
| 2 |
237-65 |
O-RING Price: $2.50 |
| 2 |
583512701 |
SUBASM.AXLE.CAST.NZTR. This part replaces 532436870. Price: $169.99 |
| 3 |
86-2740 |
HOSE ASSY Price: $201.47 |
| 4 |
32128-23 |
NUT-HF Price: $1.51 |
| 4 |
583512801 |
WELDMENT.SPINDLE.LH.15.NZTR This part replaces 532436873. Price: $29.99 |
| 5 |
583512901 |
WELDMENT.SPINDLE.RH.15.NZTR This part replaces 532436874. Price: $24.99 |
| 5 |
74-6230 |
TUBE ASM Price: $117.52 |
| 6 |
237-22 |
O-RING Price: $2.43 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
76-9290 |
BRACKET-DRAIN, CASE Price: $9.53 |
| 8 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
340-70 |
NUT-LOCK Price: $2.10 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
76-8180 |
DISCONTINUED Price: Call Us |
| 11 |
74-6260 |
DISCONTINUED Price: Call Us |
| 12 |
74-6270 |
TUBE - ASSY STR RH Price: $140.99 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
74-6450 |
BRACKET-BULKHEAD, STEERING Price: $44.73 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
76-9590 |
HOSE ASM Price: $73.44 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532444212. Price: $34.99 |
| 16 |
88-1550 |
STOP - 4WD AXLE Price: $47.56 |
| 17 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 19 |
3247-2 |
SCREW-SET, HSH Price: $0.68 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
76-6570 |
THRUST WASHER Price: $1.42 |
| 21 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532437747. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 22 |
86-2730 |
DISCONTINUED Price: Call Us |
| 23 |
325-20 |
SCREW-HH Price: $6.29 |
| 24 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 25 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 26 |
32151-96 |
RING-RETAINING Price: $0.54 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
71-4580 |
BEARING Price: $80.51 |
| 28 |
237-166 |
O-RING Price: $10.46 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
2412-74 |
R-CLAMP Price: $2.37 |
| 30 |
86-2710 |
HOSE ASM Price: $149.65 |
| 31 |
340-156 |
FITTING-ELBOW 45 Price: $67.70 |
| 32 |
237-81 |
O-RING Price: $2.76 |
| 33 |
76-6580 |
DISCONTINUED Price: Call Us |
| 34 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 35 |
325-4 |
SCREW-HH Price: $0.95 |
| 36 |
76-4200 |
DISCONTINUED Price: Call Us |
| 37 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 38 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 39 |
76-4190 |
DISCONTINUED Price: Call Us |
| 41 |
76-9200 |
REAR BUMPER WA *B Price: $534.03 |
| 42 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 43 |
74-5560 |
TIRE (20X8-10) 6-PLY Price: $118.04 |
| 44 |
217-122 |
DISCONTINUED Price: Call Us |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 48 |
74-5500 |
BOLT-WHEEL Price: $10.84 |
| 49 |
74-5620 |
DISCONTINUED Price: Call Us |
| 50 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 51 |
237-42 |
O-RING Price: $2.78 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
353-508 |
PLUG-HH Price: $7.96 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 53 |
67-9410 |
WASHER Price: $2.04 |
| 54 |
328-25 |
SCREW-HH Price: $4.07 |
| 55 |
74-3450 |
DISCONTINUED Price: Call Us |
| 56 |
237-78 |
O-RING Price: $3.85 |
| 57 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
32128-33 |
NUT-HF Price: $0.25 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
76-4170 |
PLATE - AXLE PIVOT *B Price: $186.71 |
| 61 |
597069802 |
LINKAGE SUBASM LINK DRAG LH N This part replaces 532436884. Price: $29.99 |
| 62 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 62 |
597069902 |
Links This part replaces 532436885. Price: $29.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 63 |
74-5250 |
DISCONTINUED Price: Call Us |
| 64 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
3296-45 |
NUT-HEX Price: $3.79 |
| 66 |
340-155 |
FITTING-STRAIGHT Price: $28.90 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
237-79 |
O-RING Price: $5.46 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
340-153 |
FITTING-ELBOW, 90 DEG Price: $64.96 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
321-15 |
SCREW-HH Price: $0.61 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 70 |
86-2720 |
DISCONTINUED Price: Call Us |
| 71 |
340-157 |
FITTING-HYD, TEE Price: $49.83 |
| 72 |
77-4080 |
HOSE ASSY Price: $102.96 |
| 73 |
340-160 |
FITTING-HYD-90 Price: $69.62 |
| 74 |
321-8 |
SCREW-HH Price: $0.34 |
| 75 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 76 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 80 |
532001370 |
THRUST WASHER Price: $4.99 |
| 81 |
597069702 |
Links This part replaces 532436887. Price: $9.99 |
| 82 |
532436877 |
Price: Call Us |
| 85 |
529846901 |
SERVICE KIT SUBASM.PIVOT.RH.NZ This part replaces 532441873. Price: $17.99 |
| 86 |
583561001 |
SUBASM.PIVOT.LH.NZTR This part replaces 532441872. Price: $27.99 |
| 118 |
532406013 |
BUSHING, AXLE CAST Price: $4.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
