| Ref | Part Number | Description |
|---|
| 1 |
321-5 |
SCREW-HH Price: $0.22 |
| 1 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 1 |
683-04513-0637 |
FRAME ASSEMBLY (POWDER BLACK) Not Available Price: |
| 2 |
2412-106 |
CLAMP-R Price: $2.04 |
| 2 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 2 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 3 |
539112734 |
THROTTLE CABLE Price: $29.99 |
| 3 |
710-04666 |
Hex Flange Screw, 1/4-20 x .75 Price: $6.04 |
| 4 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 4 |
576179401 |
HOUR METER This part replaces 539110074. Price: $27.99 |
| 4 |
783-04467-0637 |
DECK UP STOP BRACKET Not Available Price: |
| 5 |
539130375 |
RP.FENDER, RT Price: $44.99 |
| 5 |
710-0642 |
Hex Washer Screw, 1/4-20 x .75 Price: $4.05 |
| 6 |
539112735 |
CONSOLE.PLATE.BLACK Price: $9.99 |
| 6 |
710-3005 |
Hex Cap Screw, 3/8-16 x 1.25 Price: $3.61 |
| 6 |
92-6059 |
PLUG-BUTTON Price: $0.88 |
| 7 |
596917001 |
Screws This part replaces 539110673. Price: $2.99 |
| 7 |
712-0271 |
Sems Nut, 1/4-20 Price: $3.78 |
| 7 |
92-9273-03 |
CONSOLE-CENTER Price: $4,636.98 |
| 8 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 8 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 8 |
712-04064 |
Hex Flange Lock Nut, 1/4-20 Price: $3.64 |
| 9 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 9 |
712-04065 |
Hex Flange Lock Nut, 3/8-16 Price: $3.68 |
| 10 |
532140401 |
KEY MLD GEN DELTA This part replaces 539107544. Price: $5.99 |
| 10 |
725-0157 |
Cable Tie Price: $3.46 |
| 11 |
539130671 |
REFLECTOR, HEADLIGHT RT This part replaces 539110452. Price: $17.99 |
| 11 |
539130672 |
REFLECTOR, LEFT HEAD LIGHT This part replaces 539110456. Price: $22.99 |
| 12 |
33113-016 |
SCREW-HH Price: $0.34 |
| 12 |
539110453 |
RT HEADLIGHT LENS This part replaces 539110057. Price: $4.99 |
| 12 |
539110457 |
LEFT HEADLIGHT LENS This part replaces 539110056. Price: $4.99 |
| 12 |
925-1707D |
BATTERY Not Available Price: |
| 13 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 13 |
539110451 |
RT HEADLIGHT RIM GREY Price: $4.99 |
| 13 |
539110455 |
LEFT HEADLIGHT RIM GREY Price: $4.99 |
| 13 |
731-05659 |
Steering Shaft Bushing Price: $9.09 |
| 14 |
539130374 |
FENDER, LT Price: $74.99 |
| 14 |
738-04058 |
Shoulder Spacer, .38 x 1.0 x .7 Price: $3.86 |
| 15 |
539990362 |
SCREW 1/4 X 5/8 Price: $3.99 |
| 15 |
68-6150 |
BREATHER Price: $27.22 |
| 15 |
747-04215A |
BATTERY STRAP This part replaces 747-04215-0637. Price: $14.73 |
| 16 |
539112439 |
CHOKE CABLE This part replaces 539130209. Price: $29.99 |
| 16 |
783-04806-0637 |
PIVOT BAR BRACKET Not Available Price: |
| 16 |
98-3844 |
BREATHER TUBE ASM Price: $93.59 |
| 17 |
237-65 |
O-RING Price: $2.50 |
| 17 |
783-04844-0637 |
PIVOT SUPPORT BRACKET (RH) Not Available Price: |
| 18 |
783-04845-0637 |
PIVOT SUPPORT BRACKET (LH) Not Available Price: |
| 19 |
783-04868-0637 |
STEERING SUPPORT BRACKET Not Available Price: |
| 20 |
783-04910A-0637 |
SUPPORT BRACKET Not Available Price: |
| 20 |
93-9406 |
DECAL-GLASS, SIGHT Price: $28.02 |
| 21 |
58-5940 |
PLUG-GAGE, SIGHT Price: $184.36 |
| 21 |
783-05469-0637 |
BATTERY BRACKET TRAY Not Available Price: |
| 22 |
48-6900 |
SCREW Price: $1.52 |
| 22 |
783-05617-0637 |
SUPPORT BRACKET Not Available Price: |
| 23 |
783-05760-0637 |
BRACKET SUPPORT Not Available Price: |
| 23 |
92-5682 |
STRIP-SEALING Price: $20.71 |
| 24 |
783-05850A-0637 |
FRAME SEAT PLATE Not Available Price: |
| 25 |
58-0980-01 |
MUDGUARD-LH Price: $432.91 |
| 25 |
710-04377 |
Hex Lock Screw, 7/16-50 x 2.75 Price: $9.74 |
| 26 |
93-9407 |
DECAL-LEVER, LIFT Price: $17.21 |
| 27 |
936-0171 |
Lock Washer, 7/16 Price: $3.86 |
| 28 |
747-05056 |
BELT KEEPER ROD Not Available Price: |
| 29 |
750-04763 |
Spacer, 1.375 x 1.00 x .25 Price: $9.86 |
| 30 |
756-0978B |
Engine Pulley Price: $58.13 |
| 31 |
710-04379A |
Hex Lock Screw, 7/16-50 x 3.50 Price: $5.35 |
| 31 |
93-9425 |
DECAL-DANGER Price: $28.20 |
| 32 |
93-9408 |
DECAL-OPERATION WARNING Price: $73.30 |
| 33 |
68-7840 |
STRIP-SEALING Price: $19.08 |
| 33 |
783-04419B-0637 |
Clutch Bracket Price: $12.80 |
| 34 |
340-117 |
CAP Price: $10.30 |
| 35 |
92-5694 |
HOSE-HYDRAULIC Price: $92.15 |
| 36 |
237-79 |
O-RING Price: $5.46 |
| 37 |
58-1750-03 |
PANEL-ACCESS Price: $270.79 |
| 38 |
92-4746-01 |
MUDGUARD-RH Price: $452.39 |
| 39 |
237-22 |
O-RING Price: $2.43 |
| 42 |
92-4799 |
FITTING-TEE, HYD Price: $159.71 |
| 44 |
48-7890 |
NUT-HEX Price: $0.25 |
| 45 |
321-24 |
SCREW-HH Price: $2.31 |
| 46 |
237-80 |
O-RING Price: $6.10 |
| 47 |
58-9160 |
PLUG-DRAIN Price: $23.70 |
| 48 |
68-7810 |
PANEL-LINING Price: $140.77 |
| 49 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 50 |
48-7120 |
ELEMENT-SUCTION Price: $153.05 |
| 52 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 53 |
3256-3 |
WASHER-FLAT Price: $0.49 |
