| Ref | Part Number | Description |
|---|
| 1 |
100-6443-01 |
FRAME ASM Price: $465.51 |
| 1 |
532408007 |
BELT.V.IMPELLER Price: $29.99 |
| 2 |
532419744 |
V-BELT TRACTION 34.25 Price: $22.99 |
| 2 |
94-3405 |
BEARING-BALL Price: $22.27 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC Price: $11.99 |
| 3 |
95-7148 |
HOUSING-BEARING Price: $68.65 |
| 4 |
532180523 |
PULLEY.W/SPACER.2.75 Price: $17.99 |
| 4 |
95-1642-01 |
WEIGHT-COUNTER Price: $59.47 |
| 5 |
532426589 |
NUT.FLANGE.HEX.5/16X18.BLACK Price: $2.99 |
| 5 |
93-2569 |
SCREW-HHF Price: $1.08 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK This part replaces 585284901. Price: $3.99 |
| 8 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 9 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $2.99 |
| 10 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 11 |
33026-00 |
NUT-HEX Price: $1.02 |
| 11 |
585238401 |
ARM.ASM.TRACTION.IDLER.SNOW Price: $27.99 |
| 12 |
323-5 |
SCREW-HH Price: $0.41 |
| 12 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 13 |
532400026 |
WASHER, FLAT 3/8 Price: $2.99 |
| 13 |
99-4210 |
ROLLER-ANTI SCALP Price: $20.79 |
| 14 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $1.99 |
| 14 |
99-1615 |
REAR ROLLER ASM Price: $432.04 |
| 15 |
532426491 |
PULLEY.IMPELER. Price: $14.99 |
| 15 |
99-4209 |
SHAFT-ROLLER Price: $8.18 |
| 16 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 16 |
532426490 |
PULLEY.ENG.TRACTION Price: $11.99 |
| 17 |
874610516 |
SCREW Price: $2.99 |
| 17 |
99-8168 |
COLLAR-HOC Price: $13.54 |
| 18 |
2410-30 |
CAP-PLASTIC Price: $0.83 |
| 18 |
810040500 |
LOCKWASHER Price: $2.99 |
| 19 |
33114-025 |
SCREW-HH Price: $0.70 |
| 19 |
585540501 |
GUIDE.BELT.CHAIN.LS.SNOW This part replaces 585058201. Price: $9.99 |
| 20 |
532155415 |
WASHER.20X8.5 Price: $3.99 |
| 20 |
67-1300 |
DECAL Price: $29.99 |
| 21 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 21 |
532059289 |
STEEL WASHER Price: $2.99 |
| 22 |
33115-025 |
SCREW-HH Price: $0.61 |
| 23 |
99-1614 |
ROLLER ASM Price: $617.23 |
| 24 |
33126-040 |
SCREW-CARR Price: $2.85 |
| 25 |
99-1637-01 |
PLATE-SCRAPER Price: $25.65 |
| 26 |
99-1620-01 |
PLATE-WEIGHT, LONG Price: $47.60 |
| 27 |
33116-070 |
SCREW-HH Price: $4.14 |
| 30 |
3256-74 |
WASHER-FLAT Price: $0.27 |
| 31 |
117-0561-01 |
PLATE-PIVOT Price: $27.62 |
| 32 |
100-6449 |
ROLLER-LIFT Price: $14.58 |
| 33 |
100-6448 |
SPACER-ROLLER Price: $14.66 |
| 34 |
323-12 |
SCREW-HH Price: $1.14 |
| 35 |
88-6330 |
SPRING-EXTENSION Price: $7.99 |
| 36 |
100-9818-01 |
PLATE-MOUNT, SPRING Price: $28.16 |
| 37 |
52-2480 |
SPACER-WHEEL Price: $5.89 |
| 38 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 39 |
3256-45 |
WASHER-FLAT Price: $0.28 |
