| Ref | Part Number | Description |
|---|
| 1 |
76-5610 |
PINION-OUTPUT Price: $436.03 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
76-5630 |
GEAR-SPUR Price: $109.36 |
| 4 |
76-5640 |
GASKET-CASE & COVER Price: $57.02 |
| 6 |
95-7236 |
PIN - DOWEL This part replaces 76-5660. Price: $3.56 |
| 7 |
76-5670 |
SEAL-OIL Price: $27.67 |
| 8 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 8A |
76-5650 |
WASHER-THRUST Price: $4.91 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
76-5690 |
WASHER-THRUST Price: $7.71 |
| 10 |
76-5700 |
BEARING-THRUST Price: $21.09 |
| 11 |
76-5710 |
PLUG-DRAIN, MAGNETIC Price: $9.38 |
| 12 |
532405140 |
PULLEY.ENGINE.5.0.PD Price: $44.99 |
| 12 |
76-5720 |
SCREW-HWHTF Price: $3.07 |
| 14 |
76-6040 |
PLUG-PIPE Price: $3.65 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 15 |
92-0639 |
TRANSAXLE CASE ASM Price: $1,083.47 |
| 16 |
76-5760 |
TRANSAXLE COVER ASM Price: $1,125.72 |
| 17 |
92-0642 |
GEAR-OUTPUT Price: $362.07 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 18 |
76-5780 |
GEAR-SPUR Price: $158.15 |
| 19 |
92-0644 |
GEAR-CLUSTER Price: $570.98 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 20 |
92-0641 |
SHAFT-COUNTER Price: $258.16 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
92-0645 |
SHIFTER-GEAR & SHAFT Price: $633.78 |
| 22 |
76-5820 |
SCREW-HHF Price: $4.40 |
| 23 |
76-5830 |
BALL-STEEL Price: $3.25 |
| 24 |
95-7202 |
SPRING This part replaces 76-5840. Price: $5.26 |
| 25 |
76-5850 |
DISCONTINUED Price: Call Us |
| 26 |
76-5860 |
BEARING-NEEDLE Price: $48.93 |
| 27 |
76-5870 |
BEARING-NEEDLE Price: $46.51 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 28 |
92-0640 |
DISCONTINUED Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
76-5890 |
RING-RETAINING Price: $6.21 |
| 35 |
76-5900 |
FORK-SHIFT Price: $38.25 |
| 36 |
92-0647 |
ROD-SHIFT, HI-LOW Price: $12.09 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
92-0643 |
DISCONTINUED Price: Call Us |
| 38 |
76-5930 |
DRIVE BLOCK Price: $34.87 |
| 39 |
76-5940 |
DRIVE PIN Price: $15.24 |
| 40 |
76-5950 |
DISCONTINUED Price: Call Us |
| 41 |
76-5960 |
CARRIER-DIFFERENTIAL Price: $278.78 |
| 42 |
104-0195 |
BEARING-BALL, HI-CAP This part replaces 92-0646. Price: $63.13 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
76-5980 |
SCREW-HHF Price: $13.37 |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 45 |
76-5990 |
CARRIER-DIFFERENTIAL Price: $290.15 |
| 47 |
76-6000 |
DISCONTINUED Price: Call Us |
| 49 |
76-6010 |
SPACER Price: $18.94 |
| 50 |
76-6020 |
DISCONTINUED Price: Call Us |
| 51 |
76-6030 |
SEAL-OIL Price: $17.61 |
| 52 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
