| Ref | Part Number | Description |
|---|
| 1 |
3269-25 |
RIVET-POP Price: $0.27 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
40-9520 |
SPACER Price: $0.33 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
40-0330 |
CUSHION-RUBBER Price: $8.08 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
3250-27 |
SCREW-PPH Price: $0.22 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
69-6730-01 |
SKID ASM This part replaces 69-6730. Price: $264.77 |
| 8 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
3233-9 |
SCREW-CARR Price: $1.97 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
106-0039 |
LH WING DECK ASM This part replaces 13-4989. Price: $1,850.37 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
69-6640-01 |
HINGE-FRONT, LEFT This part replaces 69-6640. Price: $157.33 |
| 14 |
69-6900 |
SHAFT-HINGE Price: $62.29 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 15 |
69-6260 |
MAGNET Price: $58.32 |
| 16 |
256-305 |
WASHER-THRUST Price: $1.76 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
69-6670-01 |
HINGE-REAR, LEFT This part replaces 69-6670. Price: $162.98 |
| 18 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 19 |
69-6910 |
DISCONTINUED - SEE NOTES Price: Call Us |
| 20 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
69-6850 |
DISCONTINUED Price: Call Us |
| 23 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 24 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 27 |
82-4910 |
ROLLER Price: $26.42 |
| 28 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 29 |
88-9270-01 |
BRACKET-ROLLER, LH This part replaces 88-9270. Price: $110.38 |
| 30 |
5-0838 |
WASHER Price: $1.09 |
| 31 |
323-7 |
SCREW-HH Price: $0.65 |
