| Ref | Part Number | Description |
|---|
| 1 |
598602801 |
Decks This part replaces 532439817. Price: $349.99 |
| 1 |
61-8140-01 |
SEAT SUPP.COVER WA This part replaces 61-8140. Price: $296.26 |
| 2 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 3 |
68-7320 |
DISCONTINUED Price: Call Us |
| 4 |
67-1710 |
DECAL-WARNING Price: $7.83 |
| 6 |
38-4020 |
SEAT MTG WA Price: $170.51 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 8 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
68-7330 |
DECAL - CAUTION Price: $16.56 |
| 10 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 11 |
3290-54 |
RIVET-BLIND This part replaces 3269-16. Price: $0.25 |
| 12 |
59-9740 |
FLEX DRAW LATCH ASM This part replaces 249-39. Price: $36.89 |
| 13 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
44-9050 |
HOSE Price: $70.98 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
3217-6 |
NUT-HEX Price: $1.19 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 17 |
27-7180 |
CAP Price: $70.51 |
| 18 |
44-8950-03 |
AIR CLEANER TUBE This part replaces 44-8950. Price: $53.15 |
| 19 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
3258-19 |
SCREW Price: $0.42 |
| 23 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
322-3 |
SCREW-HH Price: $0.79 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 28 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 29 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
323-5 |
SCREW-HH Price: $0.41 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
37-9770 |
DISCONTINUED Price: Call Us |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
321-2 |
SCREW-HH Price: $2.79 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
38-3170 |
DISCONTINUED Price: Call Us |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 36 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 37 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 38 |
3217-5 |
NUT-HEX Price: $0.25 |
| 39 |
29-6930 |
DISCONTINUED-SEE PB#936 Price: Call Us |
| 40 |
3-6685 |
SPRING Price: $10.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 42 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 43 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 44 |
37-9590 |
DISCONTINUED Price: Call Us |
| 45 |
32121-18 |
PIN-ROLL, SLOT Price: $0.25 |
| 55 |
531171201 |
SERVICE KIT IDLER.ARM.42" This part replaces 532437110. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 190 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
