| Ref | Part Number | Description |
|---|
| 1 |
144-4153 |
RESERVOIR-HYDRAULIC This part replaces 120-9077. Price: $784.00 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532184995. Price: $219.99 |
| 2 |
323-20 |
SCREW-HH Price: $1.28 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
121-1456 |
SPACER-THIN Price: $5.19 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
115-9793 |
BREATHER Price: $53.38 |
| 7 |
136-8531 |
GROMMET This part replaces 104-0790. Price: $3.62 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
114-0002 |
PIPE-STAND Price: $70.85 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 10 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 11 |
237-101 |
O-RING Price: $2.80 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
112-6365 |
DIPSTICK Price: $73.81 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
322-7 |
SCREW-HH Price: $0.89 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
121-1533 |
SPACER-THICK Price: $9.82 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
115-7721 |
NUT-CLIP, U Price: $0.81 |
| 19 |
121-1557-0P |
MOUNT-TANK This part replaces 121-1557-03. Price: $18.23 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
353-508 |
PLUG-HH Price: $7.96 |
| 24 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
120-8810 |
HOSE-STRAINER Price: $38.16 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
2412-36 |
CLAMP-HOSE This part replaces 115-5436. Price: $1.28 |
| 27 |
114-4920 |
HOSE Price: $6.72 |
| 28 |
121-1521 |
HOSE Price: $15.83 |
