| Ref | Part Number | Description |
|---|
| 1 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 1 |
530059759 |
ASSY THROTTLE CABLE Price: $9.99 |
| 2 |
237-22 |
O-RING Price: $2.43 |
| 2 |
530057541 |
HOUSING THROTTLE FAN Price: $7.99 |
| 3 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 3 |
530016406 |
SCREW #10 PLASTITE 1.362 Price: $1.99 |
| 4 |
530015814 |
SCREW Price: $1.99 |
| 4 |
88-8220 |
VALVE-BY PASS This part replaces 25-2620. Price: $189.03 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT This part replaces 25-2600. Price: $1,923.22 |
| 5 |
530054183 |
WIRE ASSY Price: $4.99 |
| 6 |
25-2590 |
DISCONTINUED Price: Call Us |
| 6 |
530059760 |
HSG THROTTLE LH Price: $6.99 |
| 7 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 7 |
545030601 |
Kit-Switch (momentary) Price: $4.99 |
| 8 |
25-3200 |
DISCONTINUED Price: Call Us |
| 8 |
530049107 |
TRIGGER RED This part replaces 545077601. Price: $1.99 |
| 9 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 9 |
530058583 |
Assy-Handle This part replaces 530057546. Price: $4.99 |
| 10 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 10 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 11 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 11 |
530015786 |
BOLT 1/4-20 X 2 SQUARE Price: $1.99 |
| 12 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 12 |
575260201 |
KIT UPPER SHAFT BLACK Price: $27.99 |
| 13 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 13 |
545213801 |
ASSY COUPLER BLACK This part replaces 575291801. Price: $8.99 |
| 14 |
25-2700 |
DISCONTINUED Price: Call Us |
| 14 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 15 |
237-86 |
O-RING Price: $5.47 |
| 15 |
545150701 |
Bracket - Shield SST Price: $2.99 |
| 16 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 16 |
530096099 |
GEARBOX 1 Price: $32.99 |
| 17 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 17 |
530096218 |
FLEX-LOWER Price: $6.99 |
| 18 |
530071789 |
KIT LOWER SST SHAFT PWE Price: $17.99 |
| 18 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 25-2560. Price: $50.57 |
| 19 |
25-2690 |
DISCONTINUED Price: Call Us |
| 19 |
530015775 |
SCREW 8-16 X 9/16 (PLAS Price: $1.99 |
| 20 |
252-87 |
NEEDLE BRG Price: $29.99 |
| 20 |
530016014 |
SCREW - CARB. ADAPTOR Price: $1.99 |
| 21 |
253-44 |
SEAL-OIL Price: $24.63 |
| 21 |
530015820 |
BOLT, TYPE 2 Price: $1.99 |
| 22 |
322-4 |
SCREW-HH Price: $0.35 |
| 22 |
530052286 |
LINE CUTTER Price: $1.54 |
| 23 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 23 |
530015814 |
SCREW Price: $1.99 |
| 24 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 24 |
530071997 |
KIT SHIELD Price: $17.99 |
| 25 |
237-95 |
O-RING Price: $11.97 |
| 25 |
545202401 |
HEAD CUTTING FIXED LINE Price: $17.99 |
| 26 |
25-3190 |
DISCONTINUED-SEE PB#945 This part replaces 25-3220. Price: Call Us |
| 26 |
545202501 |
CAP FIXED LINE 6 Price: $3.99 |
| 27 |
25-2460 |
PLUG-HH Price: $37.38 |
| 28 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 29 |
25-2490 |
BALL Price: $14.47 |
| 30 |
251-8 |
BEARING-BALL Price: $30.06 |
| 31 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 32 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 33 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 34 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 35 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 36 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 37 |
25-2400 |
GASKET Price: $19.26 |
| 38 |
237-30 |
O-RING Price: $2.50 |
| 39 |
25-2670 |
DISCONTINUED Price: Call Us |
| 40 |
323-11 |
SCREW-HH Price: $1.08 |
| 41 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 42 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
