| Ref | Part Number | Description |
|---|
| 1 |
532192873 |
SPRING, TRACTION IDLER Price: $2.99 |
| 1 |
611-3033P |
AXLE SHAFT (RH) Not Available This part replaces 611-3033. Price: |
| 1 |
94-3230 |
DISCONTINUED Price: Call Us |
| 2 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 2 |
76-5540 |
BUSHING-INJECTOR Price: $30.77 |
| 2 |
911-3034 |
AXLE SHAFT (LH) Not Available This part replaces 611-3034. Price: |
| 3 |
618-0226 |
Collar Assembly, Hi-Lo Price: $110.25 |
| 3 |
76-5530 |
WASHER-TRAP, FLAME Price: $1.30 |
| 4 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 4 |
76-5550 |
FUEL INJECTOR GASKET This part replaces 94-3226. Price: $11.78 |
| 4 |
918-3183 |
DIFF LOCK COLLAR ASSEMBLY Not Available This part replaces 618-3183. Price: |
| 5 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 5 |
76-5520 |
DISCONTINUED Price: Call Us |
| 5 |
903-05045 |
DIFF LOCK BRACKET Not Available This part replaces 703-05045. Price: |
| 6 |
532059289 |
STEEL WASHER Price: $3.99 |
| 6 |
710-0176 |
Screw, Hex Cap, 5/16-18 x 2.75 GR5 Price: $3.89 |
| 6 |
94-3232 |
WASHER-CALIBRATION (.79) Price: $8.60 |
| 6 |
94-3242 |
WASHER-CALIBRATION (1.30) Price: $7.57 |
| 7 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532166785. Price: $4.99 |
| 7 |
710-0378 |
Screw, Hex Cap, 5/16-18 x 2.5 GR5 Price: $4.09 |
| 7 |
94-3228 |
SPRING Price: $54.06 |
| 8 |
532175330 |
PIN, IDLER PIVOT Price: $4.99 |
| 8 |
710-0602 |
Screw, Hex Wash. Hd. Tapp, 5/16-18 x 1.0 Price: $4.05 |
| 8 |
94-3227 |
SPACER Price: $42.30 |
| 9 |
532405029 |
V-BELT.TRACTION.DRIVE.SNOW.13H Price: $27.99 |
| 9 |
710-0817 |
Screw, Hex Wash. Hd. Tapp, 5/16-18 x 1.25 Price: $5.77 |
| 9 |
94-8147 |
DISCONTINUED Price: Call Us |
| 10 |
532198552 |
WASHER, LOCK 5/16 Price: $6.99 |
| 10 |
710-1880 |
Screw, Hex Cap, w/Patch 5/16-18 x .75GR5 Price: $4.02 |
| 10 |
74-8770 |
DISCONTINUED Price: Call Us |
| 11 |
532198584 |
SCREW, HEX HEAD 5/16-18 X 1/2 Price: $3.99 |
| 11 |
710-1633 |
Screw, Plug, M14 x 1.5 x .827 Price: $13.06 |
| 11 |
94-3229 |
DISCONTINUED Price: Call Us |
| 12 |
532422762 |
KIT.SERVCE.IDLER.PULLEY This part replaces 532179259. Price: $79.99 |
| 12 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 12 |
74-8750 |
INJECTION TUBE SET Price: $278.99 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 13 |
710-04035 |
SCREW .309 x .375 x 1/4-20 Not Available Price: |
| 13 |
94-3231 |
DISCONTINUED Price: Call Us |
| 14 |
532178828 |
SPRING, BRAKE Price: $4.99 |
| 14 |
911-1675 |
OUTPUT SHAFT 11T Not Available This part replaces 711-1675. Price: |
| 15 |
532403842 |
BELT.V.IMPELLER.13HPHS.SNOW Price: $39.99 |
| 15 |
911-1676 |
DIFF CROSS SHAFT Not Available This part replaces 711-1676. Price: |
| 16 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 16 |
911-1677 |
DIFF LOCK SHAFT Not Available This part replaces 711-1677. Price: |
| 17 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532187786. Price: $27.99 |
| 17 |
911-1688 |
HI LO ACTUATOR SHAFT Not Available This part replaces 711-1688. Price: |
| 18 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 18 |
711-04137 |
DRIVE SHAFT Not Available Price: |
| 19 |
532198559 |
BUSHING, IDLER PIVOT Price: $2.99 |
| 19 |
912-0273 |
Nut. Castle 5/16-24 This part replaces 712-0273. Price: $4.02 |
| 20 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 20 |
714-0135 |
Key, Woodruff, 1/4 x 3/4 Price: $4.05 |
| 21 |
715-3010 |
DOWEL PIN-1/4 x 3/4 Not Available Price: |
| 21 |
874610516 |
SCREW Price: $3.99 |
| 22 |
532179371 |
SPACER, ENGINE PULLEY Price: $7.99 |
| 22 |
916-0114 |
Retainer Ring This part replaces 716-0114. Price: $5.99 |
| 23 |
595926601 |
PULLEY This part replaces 532180478. Price: $27.99 |
| 23 |
716-0127 |
Ring, Snap Price: $10.97 |
| 24 |
532426492 |
PULLEY.ENG.IMPELLER.SNOW This part replaces 532178813. Price: $17.99 |
| 24 |
716-0180 |
Ring, Retaining Price: $10.38 |
| 25 |
532400026 |
WASHER, FLAT 3/8 Price: $7.99 |
| 25 |
716-0396 |
ROTOR CLIP Not Available Price: |
| 26 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 26 |
916-04005 |
RETAINING RING .8 This part replaces 716-04005. Price: $4.19 |
| 27 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 27 |
916-04030 |
RETAINER WIRE RING Not Available This part replaces 716-04030. Price: |
| 28 |
532193607 |
GUIDE, BELT Price: $11.99 |
| 28 |
917-0678 |
Puck. Brake This part replaces 717-0678. Price: $6.87 |
| 29 |
917-0682 |
Plate. Puck This part replaces 717-0682. Price: $8.68 |
| 30 |
532178830 |
COVER.STORAGE.SNOW Price: $2.99 |
| 30 |
717-3534 |
SPUR GEAR 12T Not Available Price: |
| 31 |
532405024 |
SCREW, HEX HEAD 1/4-20 X 1/2 Price: $3.99 |
| 31 |
917-3535 |
SPUR GEAR 34T Not Available This part replaces 717-3535. Price: |
| 32 |
717-3536 |
SPUR GEAR 19T Not Available Price: |
| 33 |
917-3537 |
SPUR GEAR 27T Not Available This part replaces 717-3537. Price: |
| 34 |
532198580 |
CLEVIS PIN Price: $4.99 |
| 34 |
917-3538 |
DIFF SPUR GEAR 56T Not Available This part replaces 717-3538. Price: |
| 35 |
532405484 |
ARM.CONTROL.AUGER Price: $7.99 |
| 35 |
917-3541A |
BEVEL GEAR 16T Not Available This part replaces 717-3541. Price: |
| 36 |
917-3542A |
BEVEL GEAR 16T Not Available This part replaces 717-3542. Price: |
| 37 |
917-3545A |
BEVEL GEAR 10T Not Available This part replaces 717-3545. Price: |
| 38 |
917-04060 |
BEVEL GEAR 13T This part replaces 717-04060. Price: $243.64 |
| 39 |
917-04061 |
BEVEL GEAR 54T Not Available This part replaces 717-04061. Price: |
| 40 |
718-3148 |
DIFF COVER Not Available Price: |
| 41 |
918-3149A |
DIFF LOCK PLATE This part replaces 718-3149. Price: $72.33 |
| 42 |
918-3150 |
THRUST BLOCK Not Available This part replaces 718-3150. Price: |
| 43 |
918-3152 |
DIFF LOCK ACTUATOR YOKE Not Available This part replaces 718-3152. Price: |
| 44 |
718-3154 |
Yoke, Shift, Hi-Lo Price: Call Us |
| 44 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 45 |
532407849 |
BRACKET, PIVOT, IDLER Price: $5.99 |
| 45 |
919-04001 |
OUTER AXLE HOUSING (LH) Not Available This part replaces 719-04001. Price: |
| 46 |
584376001 |
PAN.BOTTON.HYDRO.BLACK This part replaces 532407869. Price: $11.99 |
| 46 |
719-04002 |
COVER, TRANS. SMALL Not Available Price: |
| 47 |
719-04003 |
HOUSING, TRANS Not Available Price: |
| 47 |
871020512 |
Screw, Hex Head 5/16-18 x 3/4 Price: $2.99 |
| 48 |
532181156 |
NUT.SPEED.5/16-18 Price: $3.99 |
| 48 |
919-04004 |
INNER AXLE HOUSING (RH) Not Available This part replaces 719-04004. Price: |
| 49 |
532407843 |
FRAME ASSEMBLY Price: $54.99 |
| 49 |
919-04005 |
INNER AXLE HOUSING (LH) Not Available This part replaces 719-04005. Price: |
| 50 |
532407868 |
PLATE.REAR.HYDRO.ORANGE Price: $17.99 |
| 50 |
921-0381 |
Oil Seal This part replaces 721-0381. Price: $17.77 |
| 51 |
532429668 |
KIT.CONTROL.SHAFT.SNOW This part replaces 532406109. Price: $29.99 |
| 51 |
721-0496 |
Seal, Oil Price: $9.52 |
| 52 |
532057079 |
THRUST WASHER Price: $1.99 |
| 52 |
721-0519 |
Seal, Gland Price: $32.98 |
| 53 |
598672770 |
Keys This part replaces 532019371. Price: $5.99 |
| 53 |
921-3020A |
Seal, Oil, 1.18 ID This part replaces 721-3020A. Price: $10.75 |
| 54 |
921-04019 |
OIL PLUG Not Available This part replaces 721-04019. Price: |
| 55 |
721-04020 |
OIL PLUG Not Available Price: |
| 56 |
932-04003 |
TORSION SPRING Not Available This part replaces 732-04003. Price: |
| 57 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
| 57 |
932-04010 |
COMPRESSION SPRING Not Available This part replaces 732-04010. Price: |
| 58 |
932-04101 |
COMPRESSION SPRING .2240X .563 7000 Not Available This part replaces 732-04101. Price: |
| 59 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 60 |
736-0355 |
Washer, Flat, .56 x 1.0 x .04 Not Available Price: |
| 61 |
736-0371 |
Washer, Flat, .343 x .88 x .062 Price: $3.94 |
| 62 |
736-0615 |
Washer, Thrust Price: $8.02 |
| 63 |
736-0266 |
FLAT WASHER Not Available Price: |
| 64 |
741-0343 |
Pin, Brake Actuating Price: $8.93 |
| 65 |
941-0363 |
Flange Bearing, .503 ID x .75 OD This part replaces 741-0363. Price: $22.73 |
| 66 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 67 |
741-1104 |
BEARING BALL Not Available Price: |
| 68 |
941-3033A |
Bearing, Ball This part replaces 741-3033A. Price: $50.07 |
| 69 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 70 |
741-3083 |
Bearing, Needle Thrust Price: $14.74 |
| 71 |
941-04014 |
BALL BEARING 6007 Not Available This part replaces 741-04014. Price: |
| 72 |
941-04066 |
BALL BEARING Not Available This part replaces 741-04066. Price: |
| 73 |
950-3364 |
SPACER Not Available This part replaces 750-3364. Price: |
| 74 |
950-04024 |
SPACER Not Available This part replaces 750-04024. Price: |
| 75 |
950-04088 |
SPACER Not Available This part replaces 750-04088. Price: |
| 76 |
761-0215 |
Disc, Brake Price: $19.46 |
| 77 |
961-04000 |
BRAKE YOKE ASSEMBLY This part replaces 761-04000. Price: $102.66 |
| 78 |
961-04001 |
ANTI ROTATION PLATE Not Available This part replaces 761-04001. Price: |
| 79 |
961-04002 |
PUCK RETAINING PLATE Not Available This part replaces 761-04002. Price: |
| 80 |
961-04003 |
BRAKE ACTRUATOR ARM (LH) Not Available This part replaces 761-04003. Price: |
| 81 |
961-04004A |
BRAKE ACTRUATOR ARM (RH) Not Available This part replaces 761-04004A. Price: |
