| Ref | Part Number | Description |
|---|
| 1 |
120-2159 |
NO. 1 LIFT ARM ASM Price: $505.71 |
| 2 |
120-2162 |
NO. 5 LIFT ARM ASM Price: $517.48 |
| 3 |
120-2163 |
NO. 4 LIFT ARM ASM Price: $517.48 |
| 4 |
120-2084 |
PIN-LIFTARM Price: $208.51 |
| 5 |
121-7855 |
BUMPER-RECESSED Price: $10.34 |
| 6 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 7 |
120-9219 |
PIN-CYLINDER Price: $52.18 |
| 8 |
131-4295 |
PIN-PIVOT Price: $51.39 |
| 9 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 10 |
120-2158 |
PIN Price: $72.52 |
| 11 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 12 |
163-3530 |
CYLINDER-HYDRAULIC This part replaces 119-6988. Price: $515.30 |
| 13 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 14 |
92-1298 |
PIN-LYNCH Price: $2.27 |
| 15 |
94-3452 |
PIN Price: $10.04 |
| 16 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 17 |
32120-72 |
RING-SNAP Price: $2.09 |
| 18 |
163-3532 |
CYLINDER-HYDRAULIC This part replaces 120-9980. Price: $682.76 |
| 19 |
120-2183 |
WASHER-THRUST Price: $2.99 |
| 20 |
120-9962 |
HOOP-CHAIN Price: $20.74 |
| 21 |
63-8410 |
WASHER Price: $1.76 |
| 22 |
323-7 |
SCREW-HH Price: $0.65 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
84-2450 |
CHAIN-STRAIGHT, 4-LINK Price: $7.74 |
| 25 |
140-6244 |
PIVOT YOKE ASM Price: $369.38 |
| 26 |
323-6 |
SCREW-HH Price: $0.66 |
| 27 |
107-4027 |
CAP Price: $12.59 |
| 28 |
107-7400 |
PIN-LYNCH Price: $9.56 |
