| Ref | Part Number | Description |
|---|
| 1 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 3 |
136-3375 |
NO.1 LIFTARM ASM This part replaces 108-4032. Price: $856.35 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
131-4201 |
PIN-PIVOT This part replaces 104-5525. Price: $20.50 |
| 4 |
532404472 |
HUSQ.GRILLE.CROWN.LOGO This part replaces 532199348. Price: $14.99 |
| 5 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 5 |
532408703 |
DASH Price: $54.99 |
| 6 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 7 |
328-7 |
SCREW-HH Price: $4.00 |
| 8 |
127-6429 |
LIFT CYLINDER ASM This part replaces 107-1979. Price: $710.40 |
| 9 |
127-6427 |
LIFT CYLINDER ASM This part replaces 107-1980. Price: $652.96 |
| 10 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 11 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 12 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 13 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 14 |
125-1906 |
PIN-CYLINDER This part replaces 105-9889. Price: $27.84 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 17 |
105-3987-03 |
PLATE-SKID Price: $42.52 |
| 18 |
136-3377 |
NO.4 LIFTARM ASM This part replaces 108-4033. Price: $866.36 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 19 |
323-7 |
SCREW-HH Price: $0.65 |
| 20 |
108-4023 |
SHAFT-CARRIER, PIVOT Price: $62.44 |
| 21 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 22 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 23 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 24 |
104-5585 |
BRACKET-SWITCH Price: $21.55 |
| 25 |
106-9288 |
SENSOR-PROXIMITY, FERROUS Price: $126.57 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 27 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 28 |
104-5689-03 |
BRACKET-SUPPORT, BUMPER Price: $62.97 |
| 29 |
87-3470 |
BUMPER Price: $18.89 |
| 31 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 32 |
105-9831-03 |
BRACKET-BUMPER, NO. 1 Price: $26.24 |
| 33 |
104-5680-03 |
FRAME-CARRIER, FRONT Price: $1,713.36 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 35 |
136-3510 |
CARRIER FRAME ASM This part replaces 115-3453. Price: $664.28 |
| 36 |
112-9900-03 |
GUARD-FOOT Price: $82.81 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
323-52 |
SCREW-HH Price: $3.63 |
| 37 |
597652401 |
SERVICE KIT FENDER.TLT.CPH.615 This part replaces 532404794. Price: $219.99 |
| 38 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 39 |
105-9823 |
BUSHING-CARRIER Price: $5.52 |
| 40 |
105-9822 |
SPACER Price: $3.16 |
| 41 |
323-11 |
SCREW-HH Price: $1.08 |
| 42 |
321-15 |
SCREW-HH Price: $0.61 |
| 43 |
32128-33 |
NUT-HF Price: $0.25 |
| 44 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 46 |
136-3379 |
NO.5 LIFTARM ASM This part replaces 108-4034. Price: $894.10 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY This part replaces 532402954. Price: $4.99 |
| 150 |
532198513 |
AIR.DUCT.TEXGT.HUSQ.SV Price: $37.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
579841501 |
KITS.CHASSIS.WELD.SERVICE This part replaces 532195457. Price: $219.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
532414579 |
CONSOLE.ASM.DECKLFT.BL/RBT.TLT This part replaces 532402843. Price: $22.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 222 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 230 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 239 |
532110452 |
NUT PUSH M Price: $2.99 |
