| Ref | Part Number | Description |
|---|
| 1 |
130-2680-0P |
CHAMBER-OUTER This part replaces 130-2680-01. Price: $250.27 |
| 1 |
872040410 |
BOLT Price: $3.99 |
| 2 |
130-2681-0P |
CHAMBER-INNER This part replaces 130-2681-01. Price: $357.29 |
| 2 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532127398. Price: $149.99 |
| 3 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 3 |
874641008 |
SCREW ** Price: $2.99 |
| 4 |
3296-45 |
NUT-HEX Price: $3.79 |
| 4 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 5 |
29-4820 |
ROLLER Price: $14.88 |
| 5 |
532139888 |
BOLT.SHOULDER.5/16-18 This part replaces 532105529. Price: $3.99 |
| 6 |
325-17 |
SCREW-HH Price: $2.90 |
| 6 |
532124967 |
CLIP T Price: $5.46 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
873951000 |
Nut, Hex, Keps #10-32 UNF Price: $6.99 |
| 8 |
107-3154 |
NUT-PUSH Price: $0.99 |
| 8 |
874760612 |
BOLT Price: $3.99 |
| 9 |
100-5668-03 |
PLATE-COVER, RH SIDE Price: $77.06 |
| 9 |
532126656 |
BRKT,SEAT PIVOT Price: $5.46 |
| 10 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 10 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 11 |
1-804254 |
NUT-LOCK, HH Price: $1.29 |
| 11 |
596134901 |
GSPH This part replaces 819131210. Price: $2.99 |
| 12 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 12 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 13 |
100-5665-03 |
PLATE-COVER, RH Price: $73.07 |
| 14 |
100-5666 |
COVER-MOTOR, RH DECK Price: $139.21 |
| 14 |
810040800 |
LOCKWASHER Price: $5.99 |
| 15 |
819171912 |
WASHER Price: $3.99 |
| 16 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 17 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 17 |
532121251 |
STRIP FORM Price: $5.46 |
| 18 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 19 |
532121248 |
BUSHING Price: $4.99 |
| 20 |
532121250 |
SPRING Price: $3.99 |
| 21 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 23 |
532124294 |
PAN SEAT Price: $14.69 |
