| Ref | Part Number | Description |
|---|
| 1 |
710-0528 |
Hex Bolt 5/16-18 x 11/4" Lg. Price: $3.90 |
| 2 |
720-04083 |
Grip This part replaces 720-0180. Price: $12.95 |
| 5 |
710-0458 |
CARRIAGE BOLT 5/16-18 x 1.75 Price: $3.72 |
| 9 |
15093C |
BRACKET-CL Not Available Price: |
| 10 |
710-0607 |
Hex Wash. S-Tap Scr. 5/16-18 x .62" Lg. Price: $6.06 |
| 11 |
712-0256 |
HEX JAM NUT 5/16-24 Not Available Price: |
| 12 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 13 |
946-0484 |
Tine Clutch Control Cable This part replaces 746-0484. Price: $58.36 |
| 14 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 15 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 16 |
784-0036A |
HANDLE PANEL Not Available Price: |
| 17 |
749-0637 |
Handle-L. H . Price: Call Us |
| 18 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 19 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 20 |
736-0105 |
Bell-Wash. 3/8" I.D. Price: $3.96 |
| 21 |
710-0514 |
Hex Bolt 3/8-16 x 1" Lg. This part replaces 710-0253. Price: $3.78 |
| 22 |
714-0507 |
Cotter Pin 3/32" Dia. x 3/4" Price: $3.93 |
| 23 |
725-0157 |
Cable Tie Price: $3.46 |
| 24 |
747-0432 |
Tiller Flap Rod Price: $12.08 |
| 25 |
14989 |
End Cover Ass'y.-L.H. Price: Call Us |
| 26 |
736-0242 |
Bell-Wash. 5/16" I.D. Price: $3.75 |
| 27 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 29 |
15397 |
L.H. TINE ASS'Y. COMP. Not Available Price: |
| 30 |
712-0241 |
Hex Nut 3/8-24 Thd. Price: $3.86 |
| 31 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 32 |
710-0191 |
Hex Bolt 3/8-24 x 1.25" Lg. Price: $4.02 |
| 33 |
714-0149B |
Inter. Cotter Pin This part replaces 714-0149. Price: $3.95 |
| 34 |
14978 |
ADAPTER AS Not Available Price: |
| 35 |
1916946001 |
Tine 12" R.H. Not Available This part replaces 742-0106. Price: |
| 36 |
742-0105 |
TINE 12 L.H. Not Available Price: |
| 37 |
711-0415 |
Clevis Pin 3/8" Dia. Price: $4.04 |
| 38 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 39 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 40 |
786-0113 |
Rear Tine Shield This part replaces 14979. Price: $60.57 |
| 41 |
710-0736 |
BOLT-HEX 5/16-18X1 Not Available Price: |
| 42 |
738-0507B |
Shld. Bolt 1/2" Dia. x .426" Price: $3.86 |
| 43 |
936-0117 |
Fl-Wash. This part replaces 736-0117. Price: $6.20 |
| 44 |
710-0216 |
Hex Bolt 3/8-16 x 3/4" Lg. Price: $3.93 |
| 45 |
786-0120-0637 |
Depth Bar This part replaces 14992. Price: $58.29 |
| 46 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 47 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 48 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 49 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 51 |
726-0175 |
CLAMP Not Available Price: |
| 52 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 53 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 54 |
710-0118 |
Hex Bolt 5/16-18 x 3/4" Lg. Price: $3.76 |
| 55 |
920-0232 |
Knob This part replaces 720-0165. Price: $9.11 |
| 56 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 57 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 58 |
710-0118 |
Hex Bolt 5/16-18 x .75" Lg. Price: $3.76 |
| 59 |
15393 |
BRACKET REINFORCEMENT Not Available Price: |
| 61 |
784-0026 |
TINE SHIELDCOLOR Not Available Price: |
| 62 |
714-0149B |
Inter. Cotter Pin This part replaces 714-0149. Price: $3.95 |
| 63 |
711-0415 |
Clevis Pin 3/8" Dia. Price: $4.04 |
| 64 |
749-0762 |
HANDLE (RH) Not Available Price: |
| 65 |
720-0195 |
Hand Knob Price: $13.68 |
| 66 |
714-0127 |
COTTER PIN-1/16 DIA x .75 Not Available Price: |
| 67 |
712-0375 |
Hex Cent. L-Nut 3/8-16 Thd. Price: $4.02 |
| 69 |
938-0560 |
Shoulder Bolt .374 Dia. x 1.53" Lg. This part replaces 738-0560. Price: $9.09 |
| 70 |
741-0402 |
BEARING-FL Not Available Price: |
| 71 |
938-0561 |
SHOULDER NUT Not Available This part replaces 738-0561. Price: |
| 72 |
946-0502 |
Throttle Control Wire This part replaces 746-0502. Price: $21.85 |
| 73 |
831-0823A |
Throttle Control Box Ass'y. Price: $30.59 |
| 74 |
936-0219 |
Bell-Wash. .400" I.D. x 1.13" O.D. This part replaces 736-0219. Price: $3.86 |
| 75 |
784-0022 |
BRACKET Not Available Price: |
| 76 |
738-0281 |
Shoulder Bolt Price: $9.16 |
| 77 |
784-0019 |
HANDLE MOUNTING BRKT Not Available Price: |
| 78 |
784-0025 |
Adj. Handle Ass'y. Price: Call Us |
| 79 |
712-0375 |
Hex Cent. L-Nut 3/8-16 Thd. Price: $4.02 |
| 80 |
736-0105 |
Bell-Wash. .40" I.D. x .88" O.D. Price: $3.96 |
| 81 |
736-0253 |
Bell-Wash. 1/2n I.D. x l.oOn O.D. Price: $3.58 |
| 82 |
711-0765 |
LOCKING PIN Not Available Price: |
| 83 |
784-0023 |
SLIDING ASSEMBLY-LOWER Not Available Price: |
| 84 |
736-0463 |
Fl-Wash. .291" I.D. x .62" O.D. Price: $3.91 |
| 85 |
732-0145 |
Compression Spring .86" O.D. x 1.00" Lg. Price: $3.74 |
| 86 |
738-0147 |
SHOULDER SCREW .500 DIA x .170 Not Available Price: |
| 87 |
710-0599 |
Hex Wash. S-Tap Scr. 1/4-20 x 50n Lg Price: $3.86 |
| 88 |
736-0242 |
Bell-Wash. 5/16 I.D. Price: $3.75 |
| 89 |
736-0285 |
Fl-Wash. 5/8" I.D. Price: $3.89 |
| 90 |
710-0779A |
Self-Tap Scr. #10 x 1/2" Lg. Price: $3.85 |
