| Ref | Part Number | Description |
|---|
| 1 |
137-6126 |
LONG REAR ROLLER ASM (3IN DIA)(32IN) This part replaces 112-8961. Price: $536.38 |
| 1 |
532124657 |
Extension, Spring (AYP part number) Price: $7.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
819091416 |
Washer, 9/32 x 7/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 4 |
874780412 |
Bolt, Hex Fin 1/4-20 x 3/4 Gr. 5 (AYP part number) Price: $2.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532139888 |
BOLT.SHOULDER.5/16-18 This part replaces 532126675. Price: $2.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
532122549 |
Bracket, Hood R. H. (AYP part number) Price: $2.45 |
| 7 |
117-0990 |
PLASTIC WIEHLE ROLLER ASM Price: $553.30 |
| 7 |
532122548 |
Bracket, Hood L.H. (AYP part number) Price: $2.99 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
817521310 |
Screw Sltd. Hex Hd W/PL Washer (AYP part number) Price: $0.99 |
| 9 |
322-16 |
SCREW-HH Price: $3.39 |
| 9 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 873800400. Price: $1.99 |
| 10 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 10 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 10 |
532123693 |
Brace, Hood (AYP part number) Price: $5.99 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
532144647 |
Hood (AYP part number) Price: Call Us |
| 12 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 12 |
532122035 |
Lens Clear Bar (AYP part number) Price: $14.99 |
| 13 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 13 |
532127029 |
Grille (AYP part number) Price: $199.99 |
| 14 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 18 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 19 |
810040400 |
LOCKWASHER This part replaces 811030400. Price: $3.99 |
| 25 |
119-0649 |
TRIM/HD COLLAR KIT Price: $24.38 |
