TRIMMER/BRUSHCUTTER ASSEMBLY
Parts (59)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 104-0545 | BED ASM Price: $1,416.99 |
| 1 | 534826802 | Screw Price: $0.99 |
| 2 | 32128-21 | NUT-HF Price: $0.39 |
| 2 | 534826522 | Handle Set Price: $3.33 |
| 3 | 534936001 | Plug Price: $3.33 |
| 3 | 98-8761-01 | GUIDE-WHEEL Price: $48.62 |
| 4 | 3231-21 | SCREW-CARR Price: $0.76 |
| 4 | 534193001 | Trigger Switch Price: $3.33 |
| 5 | 534829000 | Harness Ass'y. Price: $11.99 |
| 6 | 108-3156 | BRACKET-ROD Price: $33.17 |
| 6 | 534826801 | Screw Price: $1.99 |
| 7 | 106-5354 | SPRING-LATCH Price: $30.57 |
| 7 | 534227800 | Carbon Brush Price: $3.16 |
| 8 | 534228000 | Brush Spring Price: $1.99 |
| 9 | 105-5394 | ROD-TRAILER, LARGE Price: $19.45 |
| 9 | 534828100 | Upper Tube Price: $5.99 |
| 10 | 534829600 | Screw Price: $3.33 |
| 10 | 98-8756 | SPACER-STOP Price: $12.55 |
| 11 | 323-38 | SCREW-HH Price: $2.62 |
| 11 | 534828300 | Stop Nut Price: $3.33 |
| 12 | 534828401 | Bolt Price: $3.33 |
| 12 | 98-8677-01 | INSERT-STANDARD Price: $117.45 |
| 13 | 105-5392 | RIVET-DRIVE Price: $1.76 |
| 13 | 534282705 | Assist Handle Price: $3.33 |
| 14 | 534828500 | Wing Nut Price: $3.33 |
| 14 | 98-8776 | MAT-BED Price: $179.44 |
| 15 | 534828200 | Lower Tube Price: $4.44 |
| 15 | 98-8777 | SPACER Price: $5.64 |
| 16 | 534271692 | Housing Set Price: $17.99 |
| 17 | 534954300 | Insulator Shield Price: $1.99 |
| 18 | 534336600 | P.C. Board Ass'y. Price: $3.33 |
| 19 | 534227700 | Brush Holder Price: $3.33 |
| 20 | 534450400 | Brush Kit (Inc. 7,8,19) Price: $12.32 |
| 21 | 534790300 | Screw Price: $3.33 |
| 22 | 534768300 | Motor Ass'y. Price: $3.33 |
| 23 | 534487245 | Air Baffle Price: $3.33 |
| 24 | 534907306 | Cutting Head Ass'y. Price: $18.52 |
| 25 | 534828700 | Washer Price: $1.99 |
| 26 | 534826800 | Screw Price: $1.99 |
| 27 | 534379645 | Guard & Blade Ass'y. Price: $8.99 |
| 28 | 534900300 | Drive Adapter Price: $3.33 |
| 29 | 534400700 | Push Nut Price: $1.99 |
| 30 | 534014477 | Housing Head Price: $3.33 |
| 31 | 534908500 | Spring Price: $5.99 |
| 32 | 534899200 | Arm Price: $3.33 |
| 33 | 534908700 | Washer Price: $1.99 |
| 34 | 534136401 | Screw Price: $1.99 |
| 35 | 534900200 | Line Shield Price: $3.33 |
| 36 | 534014475 | Cam Price: $2.99 |
| 37 | 952710511 | Spool & Line Price: Call Us |
| 38 | 534036644 | Cover Price: $1.84 |
| 39 | 534228703 | Screw Price: $3.33 |
| 40 | 534227601 | Endbell Ass'y. (Drive) Price: $3.33 |
| 41 | 534228800 | Washer Price: $1.99 |
| 42 | 534227004 | Field Ass'y. Price: $22.99 |
| 43 | 534767700 | Armature Ass'y. Price: $6.16 |
| 44 | 534228802 | Washer Price: $0.99 |
| 45 | 534238903 | Washer Price: $1.99 |
| 46 | 534227501 | Endbell Ass'y. (Brush) Price: $3.33 |
