| Ref | Part Number | Description |
|---|
| 1 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 1 |
817541011 |
Screw, Tapping #10-24 x .668 Price: $9.47 |
| 2 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 2 |
532160672 |
GEAR CASE, UPPER Price: $8.99 |
| 2 |
779-3348 |
LABEL-FLAG Not Available Price: |
| 3 |
532057072 |
SEAL Price: $4.99 |
| 3 |
60-2160 |
R-CLIP ASM Price: $8.47 |
| 3 |
710-3038 |
Screw, Hex Cap, 5/16-18 X .88 Lg GR5 Price: $4.17 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
532183908 |
SHAFT.DRIVE.HI-VAC.EZ Price: $32.99 |
| 4 |
736-0159 |
Washer, Flat, .344 X .875 X .06 Thk Price: $3.71 |
| 5 |
33095-00 |
WASHER-FLAT This part replaces 48-9580. Price: $0.25 |
| 5 |
532160818 |
BEARING, NEEDLE, THRUST Price: $4.99 |
| 5 |
932-3069 |
COMPRESSION SPRING1.28 OD x 2.18 Not Available This part replaces 732-3069. Price: |
| 6 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 6 |
532077881 |
BEARING Price: $24.99 |
| 6 |
722-0160 |
RUBBER BUSHING .318IDX.930OD Not Available Price: |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 7 |
532160817 |
WASHER, THRUST Price: $3.99 |
| 7 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
| 8 |
532850848 |
HI PRO KEY Price: $4.99 |
| 8 |
65-5890 |
CAP-END Price: $8.09 |
| 8 |
703-1813 |
SEAT CHANNEL Not Available Price: |
| 9 |
532184134 |
SHAFT.WORM.HI-VAC Price: $13.99 |
| 9 |
58-1650 |
ROD-SEAT Price: $110.80 |
| 9 |
738-0145 |
Screw, Shoulder, .500 Dia X .840 Price: $6.01 |
| 10 |
532160679 |
GEAR, HELICAL Price: $27.99 |
| 10 |
732-3060 |
COMPRESSION SPRING Not Available Price: |
| 10 |
82-9340 |
LEVEL SWITCH ASM Price: $201.99 |
| 11 |
532160676 |
KIT.GEARCASE.HALVES.RWGD.21" This part replaces 532160673. Price: $14.99 |
| 11 |
65-5870 |
TUBE Price: $20.33 |
| 11 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 12 |
532057079 |
THRUST WASHER Price: $1.99 |
| 12 |
71-4040 |
HYD FILLER ASM Price: $69.67 |
| 12 |
712-3017 |
HEX NUT 3/8-16 GR5 Price: $3.90 |
| 13 |
353-961 |
FLANGE Price: $29.89 |
| 13 |
710-3215 |
BOLT-SHT NK CARR 5/16-18X Not Available Price: |
| 13 |
812000039 |
KLIP RING Price: $4.99 |
| 14 |
32144-107 |
SCREW Price: $0.68 |
| 14 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW Price: $3.99 |
| 14 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 15 |
353-963 |
GASKET Price: $4.33 |
| 15 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 16 |
62-2610 |
STRAINER-CAP, FILLER Price: $22.31 |
| 16 |
703-1844 |
SLIDE-SEAT Not Available Price: |
| 17 |
46-0670 |
SCREW-PPH Price: $1.89 |
| 17 |
703-1843 |
ADJUSTER-MAN SEAT RIGHT Not Available Price: |
| 18 |
710-3216 |
SCREW-SOCKET HD 5/16-18X1.0 LG Not Available Price: |
| 18 |
92-9200 |
COVER Price: $276.63 |
| 19 |
60-5580 |
SWITCH-TEMPERATURE Price: $178.50 |
| 19 |
703-1811 |
BRACKET, SEAT PIVOT SUPPORT Not Available Price: |
| 20 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 20 |
703-1812 |
BRACKET, SEAT PIVOT Not Available Price: |
| 21 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 21 |
738-0140 |
Screw, Shoulder, .437 Dia X .180 Price: $4.93 |
| 22 |
58-6820 |
GASKET Price: $13.28 |
| 22 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 23 |
736-0242 |
Washer, Bell, .345 X .88 X .060 Thk Price: $3.75 |
| 23 |
93-6686 |
DECAL-OIL, HYD This part replaces 93-8067. Price: $7.01 |
| 24 |
60-0050 |
SPRING-TRAY, SEAT Price: $78.73 |
| 25 |
58-1640 |
PIN-PIVOT, SEAT Price: $59.26 |
| 26 |
68-7850 |
STRIP-SEALING Price: $41.39 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 30 |
58-1580-03 |
FRAME-SEAT This part replaces 58-1580. Price: $402.10 |
| 31 |
58-9830-03 |
PLATE-SEAT This part replaces 58-9830. Price: $355.56 |
| 32 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
2412-102 |
CLAMP-R Price: $6.85 |
