| Ref | Part Number | Description |
|---|
| 1 |
703-1578 |
Shaft Assy, Lift Price: Call Us |
| 1 |
92-5536-03 |
TUBE-CONTROL, PUMP ASM This part replaces 92-5536. Price: $203.02 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
537180711 |
HANDLE HALF LEFT Price: $17.99 |
| 2 |
703-1602 |
LINK 12.0 LG. Not Available Price: |
| 3 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 3 |
537160703 |
STARTER THROTTLE LOCK This part replaces 537160701. Price: $4.99 |
| 3 |
703-1601 |
LIFT LINK Not Available Price: |
| 4 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 4 |
537174201 |
SPRING Price: $4.99 |
| 4 |
936-0101 |
Fl-Wash. .375" I.D. x 1.00" O.D. x .030" Not Available This part replaces 736-0101. Price: |
| 5 |
27-3680 |
SPACER-MOUNTING Price: $6.65 |
| 5 |
506497701 |
THROTTLE CONTROL Price: $6.99 |
| 5 |
714-0474 |
Pin, Cotter, 1/8 X 3/4 Lg Price: $4.08 |
| 6 |
703-1595 |
REAR CAM ASSEMBLY (LH) Not Available Price: |
| 6 |
99-5677 |
TRANSMISSION ASM This part replaces 92-5513. Price: $4,071.30 |
| 7 |
237-42 |
O-RING Price: $2.78 |
| 7 |
537174301 |
SPRING Price: $3.99 |
| 7 |
903-1594 |
REAR LIFT CAM ASSEMBLY (RH) Not Available This part replaces 703-1594. Price: |
| 8 |
353-979 |
FITTING-STR Price: $12.62 |
| 8 |
503216618 |
SCREW Price: $3.99 |
| 8 |
938-0150 |
SHOULDER SCREW .625 DIA x .960 Not Available This part replaces 738-0150. Price: |
| 9 |
537180811 |
HANDLE HALF RIGHT Price: $17.99 |
| 9 |
66-3110 |
FITTING-HYD, 90 DEG Price: $61.37 |
| 9 |
741-0591 |
Flange Bearing This part replaces 741-0295. Price: $4.02 |
| 10 |
27-4370 |
HUB-PUMP Price: $70.04 |
| 10 |
503200782 |
SCREW IHSCFM This part replaces 503200735. Price: $3.99 |
| 10 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 11 |
503221013 |
NUT Price: $3.99 |
| 11 |
712-3000 |
Nut, Hex Center Lock, 3/8-16 GR5 Price: $3.90 |
| 12 |
3210-5 |
SCREW-HH Price: $0.54 |
| 12 |
537419001 |
STOP BUTTON Price: $7.99 |
| 12 |
903-1597 |
FRONT LIFT CAM ASSEMBLY (LH) Not Available This part replaces 703-1597. Price: |
| 13 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 13 |
537172803 |
HANDLE Price: $8.99 |
| 13 |
703-1598 |
Cam Assy, Front Lift - RH Price: $146.73 |
| 14 |
32152-5 |
NUT-HEX Price: $0.54 |
| 14 |
731231405 |
NUT M6M M5 Price: $2.99 |
| 14 |
911-0332 |
Clevis Pin, .50 x .78 This part replaces 711-3241. Price: $14.98 |
| 15 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 15 |
537172902 |
BRACKET Price: $4.99 |
| 15 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 16 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 16 |
503200245 |
SCREW Price: $3.99 |
| 16 |
714-0149B |
Hairpin Cotter This part replaces 714-0149. Price: $3.95 |
| 17 |
63-6610-03 |
DRIVE SHAFT ASM This part replaces 63-6610. Price: $79.41 |
| 17 |
725238281 |
SCREW EHHM This part replaces 725238285. Price: $3.99 |
| 17 |
911-3239 |
REAR LIFT LINK Not Available This part replaces 711-3239. Price: |
| 18 |
502203801 |
HANDLE Price: $5.99 |
| 18 |
736-0185 |
Washer, Flat, .406 X .75 X .063 Thk Price: $3.43 |
| 19 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 19 |
537129001 |
HANDLE HOLDER UPPER Price: $22.99 |
| 19 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 20 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 20 |
502282101 |
WASHER Price: $2.99 |
| 21 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 21 |
503200225 |
SCREW Price: $2.99 |
| 22 |
27-6590 |
SPACER-COUPLING, RUBBER Price: $13.38 |
| 22 |
505433303 |
HANDLE Price: $37.99 |
| 23 |
596283301 |
HANDLEBAR BRACKET KIT This part replaces 537129101. Price: $24.99 |
| 23 |
66-8490 |
HOSE-HYD Price: $140.41 |
| 24 |
3210-8 |
SCREW-HH Price: $1.02 |
| 25 |
237-22 |
O-RING Price: $2.43 |
| 26 |
82-8530 |
FITTING-STR,ORIF Price: $36.90 |
| 27 |
23-2300 |
FILTER-OIL, TRANSMISSION Price: $11.03 |
| 28 |
323-39 |
SCREW-HH Price: $1.60 |
| 29 |
27-9620 |
SCREW-HH Price: $16.90 |
| 30 |
5-0652 |
SPACER Price: $5.35 |
| 31 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 32 |
92-5085 |
UNION-FILTER Price: $86.00 |
| 33 |
92-5087 |
SEAL-ADAPTOR, FILTER Price: $25.51 |
| 34 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 35 |
92-5082 |
HOSE-HYD Price: $25.51 |
| 36 |
86-7220 |
GEAR-PINION Price: $81.33 |
| 37 |
32120-72 |
RING-SNAP This part replaces 936125. Price: $2.09 |
| 38 |
27-3690 |
GASKET-TRANSMISSION Price: $8.27 |
| 39 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 40 |
2412-4 |
CLAMP-R Price: $4.22 |
| 41 |
63-7170 |
ANCHOR-TRANSMISSION Price: $37.61 |
| 42 |
3218-3 |
NUT-JAM Price: $0.25 |
| 43 |
67-1900 |
SCREW-HH Price: $3.46 |
| 44 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 45 |
92-5076 |
ADAPTER-FILTER Price: $266.19 |
| 46 |
237-79 |
O-RING Price: $5.46 |
| 47 |
92-5086 |
FITTING-ELBOW, 90 DEG Price: $53.77 |
| 48 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 49 |
92-5083 |
HOSE-HYD Price: $25.27 |
| 50 |
3220-7 |
NUT-JAM Price: $4.09 |
| 51 |
237-78 |
O-RING Price: $3.85 |
| 52 |
92-5512 |
FITTING-STR Price: $21.46 |
| 55 |
353-988 |
PLUG-HEX Price: $10.61 |
| 56 |
353-990 |
PLUG ASM Price: $10.01 |
| 57 |
38-3400 |
GUARD-RUBBER Price: $8.02 |
