| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532424068. Price: $159.99 |
| 1 |
703-0064 |
FENDER Not Available Price: |
| 1 |
98-2163 |
HARNESS-WIRE, MAIN Price: $370.20 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
731-3070 |
INSTRUMENT PANEL Not Available Price: |
| 3 |
710-3009 |
Screw, Pan Hd Cutting, #10-24 X .75 Lg Price: $6.24 |
| 3 |
98-2161 |
CABLE-BATTERY, POSITIVE Price: $29.42 |
| 4 |
735-3002 |
GROMMET-INSTR PANEL Not Available Price: |
| 4 |
95-7144 |
POSITIVE CABLE ASM Price: $37.53 |
| 5 |
946-3001 |
CHOKE CONTROL 35 x 1.75 Not Available This part replaces 746-3001. Price: |
| 5 |
98-0604 |
NEGATIVE CABLE ASM Price: $32.22 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
