| Ref | Part Number | Description |
|---|
| 1 |
133-2911 |
LIFT ARM ASM #1 This part replaces 110-0991. Price: $382.73 |
| 2 |
133-2914 |
LIFT ARM ASM #4 This part replaces 114-8874. Price: $382.73 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
133-2915 |
LIFT ARM ASM #5 This part replaces 110-0995. Price: $616.56 |
| 4 |
117-0208 |
SHAFT-PIVOT, LIFTARM Price: $96.42 |
| 5 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 6 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 11 |
117-5154-01 |
PLATE-BRIDGE 1 AND 4 Price: $38.81 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 12 |
327-7 |
SCREW-HH Price: $5.69 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
110-0922 |
HOOP-CHAIN Price: $15.10 |
| 14 |
63-8410 |
WASHER Price: $1.76 |
| 15 |
323-7 |
SCREW-HH Price: $0.65 |
| 16 |
138-1248 |
PIVOT YOKE ASM This part replaces 107-2052. Price: $429.41 |
| 17 |
92-1298 |
PIN-LYNCH Price: $2.27 |
| 18 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
117-5153-01 |
PLATE-BRIDGE 5 Price: $35.44 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 21 |
596321701 |
Screws Price: $2.99 |
| 22 |
107-4027 |
CAP Price: $12.59 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 24 |
325-5 |
SCREW-HH Price: $1.20 |
| 25 |
84-2450 |
CHAIN-STRAIGHT, 4-LINK Price: $7.74 |
| 26 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 30 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers Price: $2.99 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606901 |
BOLT.HEX.7/16-20X3.GR5.YELLOW Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
