| Ref | Part Number | Description |
|---|
| 0 |
640230 |
CARBURETOR-NLA This part replaces 632948. Price: Call Us |
| 1 |
114-5422 |
ROLLER-SHOULDER, PLASTIC Price: $525.86 |
| 1 |
632947 |
SHAFT & LEV Price: $18.80 |
| 1 |
72050411 |
Bolt, Carriage 1/4-20 x 1-3/8 (AYP part number) Price: Call Us |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
140116 |
Seat (AYP part number) Price: Call Us |
| 2 |
632938 |
SPRING Price: $3.83 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
155925 |
Pan, Seat (AYP part number) Price: Call Us |
| 3 |
632926 |
CLIP Price: Call Us |
| 3A |
632950 |
SCREW Price: Call Us |
| 3B |
632949 |
SPACER Price: Call Us |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
632939A |
WASHER This part replaces 632939. Price: Call Us |
| 4 |
73800500 |
Locknut, Hex w/Ins 5/16-18 Price: Call Us |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
153236 |
Bolt, Shoulder 5/16-18 UNC (AYP part number) Price: Call Us |
| 5 |
632929 |
WASHER Price: $3.81 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
145006 |
Clip, Push-In Hinged Price: Call Us |
| 6 |
632930 |
SHUTTER Price: $10.29 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
632931 |
SCREW Price: $2.57 |
| 8 |
74760616 |
Bolt, Fin Hex 3/8-16 UNC x 1 Price: Call Us |
| 9 |
140551 |
Bracket, Pivot Seat Price: Call Us |
| 10 |
126471X |
Clip, Insulated Price: Call Us |
| 11 |
19133210 |
Washer 12/32 x 2 x 10 Ga. Price: Call Us |
| 12 |
73800600 |
Nut, Lock Hex w/Wsh 3/8-16 Price: Call Us |
| 13 |
74780814 |
Bolt Hex 1/2-13 x 7/8 (AYP part number) Price: Call Us |
| 14 |
10040800 |
Washer Lock Hvy. Hlicl Spring 1/2 Price: Call Us |
| 15 |
19171912 |
Washer, 17/32 x 1-3/16 x 12 Ga. Price: Call Us |
| 16 |
127018X |
Bolt, Shoulder Price: Call Us |
| 17 |
121246X |
Bracket, Switch, Mounting Price: Call Us |
| 17 |
632946 |
SCREW Price: $6.48 |
| 18 |
123976X |
Nut, Hex Large Flange Lock (AYP part number) Price: Call Us |
| 19 |
121248X |
Bushing, Snap Price: Call Us |
| 20 |
121250X |
Spring, Compression Price: Call Us |
| 20 |
632911 |
SCREW Price: $8.60 |
| 21 |
632912 |
SPRING Price: $2.60 |
| 27 |
632916 |
PIN Price: $2.49 |
| 28 |
632915 |
LEVER Price: $2.60 |
| 30 |
632918 |
INLET NEEDLE Price: $7.48 |
| 31 |
632920 |
SPRING Price: $2.60 |
| 34 |
632917 |
SCREW Price: Call Us |
| 40 |
632937 |
FUEL JET Price: $15.72 |
| 40A |
632951 |
JET CAP Price: Call Us |
| 45 |
632919 |
SCREEN Price: $2.45 |
| 48 |
632902 |
WELCH PLUG Price: Call Us |
| 50 |
632904 |
DIAPHRAGM Price: $14.93 |
| 51 |
632903 |
GASKET Price: $2.60 |
| 52 |
632905 |
COVER Price: Call Us |
| 53 |
632943 |
SCREW Price: $2.28 |
| 60 |
632933 |
REPAIR KIT Price: Call Us |
| 62 |
640252 |
PUMP DIAPHRAGM This part replaces 632908. Price: $3.86 |
| 63 |
632907 |
GASKET Price: $2.60 |
| 64 |
632944 |
COVER Price: $7.34 |
| 65 |
632945 |
SCREW Price: $3.61 |
