| Ref | Part Number | Description |
|---|
| 1 |
58-6940 |
COOLANT ONLY DECAL Price: $7.93 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
92-5655 |
TUBE-CANOPY Price: $15.47 |
| 3 |
58-3930 |
BUSHING-OILITE Price: $15.24 |
| 4 |
58-5330 |
SPACER-HINGE, CANOPY Price: $21.23 |
| 5 |
58-1970-01 |
PLATE-HINGE, LEFT This part replaces 58-1970. Price: $199.89 |
| 6 |
92-6086 |
REAR SCREEN ASM This part replaces 92-4793. Price: $2,609.76 |
| 7 |
92-5253 |
STRIP-SEALING Price: $59.20 |
| 8 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 9 |
58-3910 |
PIN-HINGE, CANOPY Price: $70.69 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 11 |
49-2280 |
DECAL Price: $22.38 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
86-6130 |
BALL-STUD Price: $7.46 |
| 13 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 14 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 532414151. Price: $329.99 |
| 15 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 16 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
88-6760 |
SPRING-GAS Price: $143.68 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 18 |
92-5270-03 |
BAFFLE-LOWER BODY This part replaces 92-5270. Price: $65.31 |
| 19 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
3250-25 |
SCREW-PPH Price: $0.23 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 21 |
3253-2W |
Washer-Lock Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
58-5380 |
LATCH-DRAW Price: $43.60 |
| 23 |
58-7070-03 |
SPACER-LATCH, RH This part replaces 58-7070. Price: $17.58 |
| 24 |
322-3 |
SCREW-HH Price: $0.79 |
| 25 |
3250-31 |
SCREW-PPH Price: $0.25 |
| 26 |
68-6040 |
BRACKET Price: $13.03 |
| 27 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 28 |
3256-51 |
WASHER-FLAT Price: $0.19 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
92-5681 |
FOAM-HOOD, LH Price: $187.22 |
| 31 |
86-6470 |
DECAL - RM 4500D Price: $68.10 |
| 32 |
92-4713 |
CANOPY-FRONT This part replaces 92-4712. Price: $3,149.95 |
| 33 |
92-5673-03 |
SUPPORT-FOAM, FRONT This part replaces 92-5673. Price: $46.11 |
| 34 |
92-5679 |
FOAM-HOOD, FRONT Price: $166.50 |
| 35 |
92-5672-03 |
SUPPORT-FOAM, CANOPY This part replaces 92-5672. Price: $198.05 |
| 36 |
92-5678 |
FOAM-HOOD, TOP Price: $239.26 |
| 37 |
33024-00 |
NUT-LOCK, NI This part replaces 48-9510. Price: $0.75 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
92-5652-03 |
BRACKET This part replaces 92-5652. Price: $10.46 |
| 39 |
92-6060 |
STRIP-SEALING Price: $59.20 |
| 40 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 41 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
33094-00 |
WASHER-PLAIN This part replaces 48-8030. Price: $0.25 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
93-1445 |
CENTER CANOPY-RM4500D This part replaces 92-1415. Price: $2,132.50 |
| 44 |
322-4 |
SCREW-HH Price: $0.35 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
