| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 2 |
532069180 |
LOCKNUT Price: $2.99 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
532127533 |
COVER SCREEN Price: $14.99 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
532400436 |
COVER ASM BAGGER This part replaces 532134678. Price: $229.99 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
532126840 |
CHUTE.UPPER.42" Price: $59.99 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 6 |
818021008 |
SCREW Price: $4.99 |
| 7 |
532140572 |
INDICATOR DUMP BAG Price: $6.99 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $4.99 |
| 9 |
22-8500 |
O-RING Price: $18.87 |
| 9 |
819061216 |
WASHER Price: $3.99 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 10 |
532007206 |
SPACER LT Price: $5.99 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
539108086 |
NUT 10-24 ACORN ZD This part replaces 532060867. Price: $3.99 |
| 12 |
23-3030 |
SPACER Price: $33.93 |
| 12 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 13 |
22-8480 |
RING-SNAP Price: $49.87 |
| 13 |
532109808 |
LATCH.HOOD. Price: $5.99 |
| 14 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 15 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130760. Price: $5.99 |
| 16 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130759. Price: $5.99 |
| 18 |
532145578 |
CHUTE.LOW.GT.46 Price: $83.99 |
| 20 |
596039001 |
Screws This part replaces 871161010. Price: $2.99 |
| 21 |
532132796 |
SPRING COVER LH Price: $5.99 |
| 22 |
532140809 |
SPACER BAG 3-PIN Price: $3.99 |
| 23 |
532132983 |
SPRING COVER RH Price: $5.99 |
| 24 |
874780712 |
BOLT 7/16-14X3/4 Price: $4.99 |
| 25 |
596040501 |
Hardware This part replaces 532063124. Price: $2.99 |
| 26 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 27 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 28 |
874760536 |
Bolt, Hex 5/16-18 x 2-1/4 Price: $3.99 |
| 29 |
583677201 |
POST.SUPT.3-BIN.BAG.46"GT This part replaces 532144840. Price: $5.99 |
| 30 |
532144839 |
BRACKET MTG Price: $75.99 |
| 31 |
532174083 |
PLUG, TUBING END This part replaces 532134496. Price: $5.99 |
| 32 |
532134639 |
FRAME Price: $59.63 |
| 33 |
532192786 |
BAGGER.HINGE.PIN This part replaces 532128600. Price: $14.99 |
| 34 |
532127534 |
GASKET.COVER.BAGGER Price: $11.99 |
| 35 |
532183286 |
CONTAINER TOP This part replaces 532129585. Price: $29.99 |
| 36 |
532129586 |
CONTAINER BOTTOM Price: $59.99 |
| 37 |
532134637 |
BAGGER TOP SEAL Price: $14.52 |
| 38 |
532130895 |
LATCH CER38 Price: $5.99 |
| 39 |
532139854 |
REINFORCEMENT STRIP Price: $7.71 |
| 40 |
871141008 |
Screw #10-24 x 1/2 Price: $2.99 |
| 41 |
532145326 |
PIN CLEVIS Price: $2.99 |
| 42 |
532145892 |
PLATE REINF MTG Price: $32.99 |
