| Ref | Part Number | Description |
|---|
| 1 |
98-9579 |
BAND-PIPE Price: $5.22 |
| 2 |
195223 |
Shaft Asm., Lift Price: Call Us |
| 2 |
98-9578 |
PIPE-RETURN, WATER Price: $11.28 |
| 3 |
195230 |
Lever Asm., Lift Rh Price: Call Us |
| 3 |
98-9713 |
WATER FLANGE ASM Price: $199.09 |
| 4 |
98-9719 |
THERMOSWITCH Price: $98.79 |
| 5 |
98-7777 |
BOLT Price: $1.56 |
| 6 |
98-9471 |
COVER-THERMOSTAT Price: $34.62 |
| 7 |
105-3748 |
GASKET-THERMOSTAT This part replaces 98-7776. Price: $4.31 |
| 7 |
196492 |
Grip, Lever Price: Call Us |
| 8 |
98-7778 |
THERMOSTAT ASM Price: $61.89 |
| 9 |
98-9638 |
GASKET-FLANGE, WATER Price: $3.74 |
| 10 |
196314 |
Spring Torsion Price: Call Us |
| 10 |
98-7692 |
BOLT Price: $0.92 |
| 11 |
98-9356 |
BOLT Price: $2.06 |
| 87 |
194209 |
Pin Cotter 7/16 Bow Tie Lock Price: Call Us |
| 88 |
195304 |
Spring Lift Assist Price: Call Us |
| 89 |
19191912 |
Washer Clear Zinc Price: Call Us |
| 90 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 91 |
403407 |
Link Lift Susp Mower Rear Price: Call Us |
| 97 |
17060612 |
Screw 3/8-16 x .75 Smgml Tap/R.Z Price: Call Us |
