| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 1 |
BS-212897 |
CAMSHAFT & GEAR Not Available Price: |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
BS-261183 |
TAPPET VALVE Not Available Price: |
| 3 |
BS-490348 |
CONNECTING ROD ASSEMBLY Not Available Price: |
| 4 |
BS-222299 |
LOCK Not Available Price: |
| 5 |
BS-92909 |
SCREW CONNECTING ROD Not Available Price: |
| 6 |
BS-391285 |
PISTON ASSY, STANDARD Not Available Price: |
| 7 |
BS-499996 |
PISTON RING SET STD Not Available This part replaces BS-391780. Price: |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 8 |
BS-299691 |
PIN Not Available Price: |
| 9 |
BS-260924 |
LOCK PISTON PIN Not Available Price: |
| 10 |
BS-222725 |
COVER CYLINDER HEAD Not Available Price: |
| 11 |
BS-222744 |
SHIELD CYLINDER Not Available Price: |
| 12 |
BS-398333 |
Housing, Blower Price: Call Us |
| 13 |
BS-65906 |
SPRING Not Available Price: |
| 14 |
BS-690656 |
VALVE RETAINER Not Available This part replaces BS-221596. Price: |
| 15 |
BS-26828 |
SPRING Not Available Price: |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
BS-494553 |
RETAINER-ROTO Not Available This part replaces BS-93630. Price: |
| 17 |
BS-691939 |
VALVE RETAINER Not Available This part replaces BS-292260. Price: |
| 18 |
BS-93585 |
SCREW-SEM-SUMP MOUNTING Not Available Price: |
| 19 |
BS-690946 |
Plug-Oil Drain (Square Socket) This part replaces BS-91084. Price: $5.60 |
| 20 |
BS-261185 |
VALVE EXHAUST Not Available Price: |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 21 |
BS-261462 |
VALVE INTAKE Not Available Price: |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 22 |
BS-281658S |
Cap-Oil Fill This part replaces BS-66768. Price: $4.37 |
| 23 |
BS-391086S |
Seal-Oil (Magneto Side) This part replaces BS-391086. Price: $7.18 |
| 24 |
BS-391784 |
BASE-ENGINE Not Available Price: |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $12.99 |
| 25 |
BS-271702S |
CRANKCASE GASKET Not Available This part replaces BS-271702. Price: |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 26 |
BS-291675S |
OIL SEAL Not Available This part replaces BS-291675. Price: |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 27 |
BS-491986 |
CRANK BUSHING Not Available This part replaces BS-231055. Price: |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $17.99 |
| 28 |
BS-23513 |
BUSHING Not Available Price: |
| 29 |
None |
Cylinder Assy |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 30 |
BS-691968 |
Governor/Oil Slinger This part replaces BS-490815. Price: $46.54 |
| 31 |
BS-691666 |
BREATHER ASSEMBLY SCREW Not Available This part replaces BS-93394. Price: |
| 32 |
BS-495735 |
BREATHER ASSEMBLY Not Available This part replaces BS-391406. Price: |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 33 |
BS-27803S |
BREATHER GASKET Not Available This part replaces BS-27803. Price: |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 34 |
BS-692253 |
BREATHER TUBE Not Available This part replaces BS-280100. Price: |
| 35 |
BS-222698S |
Key-Flywheel (Aluminum) This part replaces BS-222698. Price: $3.71 |
| 36 |
BS-696537 |
RING GEAR Not Available This part replaces BS-392134. Price: |
| 37 |
BS-212359 |
LINK COUNTERWEIGHT Not Available Price: |
| 38 |
BS-392299 |
CRANKSHAFT Not Available Price: |
| 39 |
BS-261196 |
Gear, Timing Price: Call Us |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $69.99 |
| 40 |
BS-391988 |
FLYWHEEL & RING GEAR ASSY - MAGNETO Not Available Price: |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 41 |
BS-391373 |
WEIGHT-COU Not Available Price: |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 42 |
BS-298909 |
Pin, Counterweight Price: $8.83 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 43 |
BS-231038 |
Spacer, Counterweight Price: Call Us |
| 44 |
BS-93875 |
Screw, Counterweight Price: Call Us |
| 45 |
BS-19203 |
Puller, Flywheel Price: $18.70 |
| 46 |
BS-691748 |
ROTATING SCREEN Not Available This part replaces BS-222562. Price: |
| 47 |
IH-77652-C1 |
SCREEN Not Available Price: |
| 48 |
BS-220865 |
Washer, Spring Price: Call Us |
| 49 |
712-3056 |
Nut, 5/8-NF Price: $4.21 |
| 50 |
BS-212914 |
HEAD, CYLINDER Not Available Price: |
| 51 |
BS-271866S |
CYLINDER HEAD GASKET Not Available This part replaces BS-271866. Price: |
| 52 |
BS-93723 |
SCREW Not Available Price: |
| 53 |
BS-298968 |
ARMATURE Not Available Price: |
| 54 |
759-3331 |
SPARK PLUG RCJ8 Not Available Price: |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 55 |
BS-66538S |
Boot-Spark Plug This part replaces BS-66538. Price: $4.77 |
| 56 |
IH-539882-R1 |
Clip, Wire Price: Call Us |
| 57 |
BS-493880S |
Terminal-Spark Plug This part replaces BS-221798. Price: $4.46 |
| 58 |
BS-391284 |
BREAKER Not Available Price: |
| 59 |
BS-65704 |
PLUNGER Not Available Price: |
| 60 |
BS-26018 |
SPRING Not Available Price: |
| 61 |
BS-29861 |
CONDENSER Not Available Price: |
| 62 |
IH-76598-C1 |
Cover, Points & Condenser Price: Call Us |
| 63 |
IH-77649-C1 |
Wire, Ground Price: Call Us |
| 65 |
BS-66068 |
Washer, Insulating Price: Call Us |
| 66 |
BS-691077 |
Washer (Ground Terminal) This part replaces BS-92791. Price: $11.38 |
| 67 |
712-0142 |
Nut, No. 8 Mach Price: $3.90 |
| 68 |
BS-66554 |
Collar, Insulating Price: Call Us |
| 70 |
BS-391507 |
RECTIFIER Not Available Price: |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $32.99 |
| 71 |
BS-261269 |
SPRING Not Available Price: |
| 72 |
BS-393304 |
Holder, Fuse Price: Call Us |
| 73 |
BS-222211 |
BRACKET Not Available Price: |
| 74 |
BS-395405 |
STARTER COVER Not Available Price: |
| 75 |
BS-93306 |
COTTER PIN Not Available Price: |
| 76 |
BS-93307 |
RETAINER Not Available Price: |
| 77 |
BS-396349 |
PLATE-CONTROL Not Available Price: |
| 78 |
BS-691024 |
Clamp-Casing This part replaces BS-221535. Price: $6.90 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 79 |
BS-690804 |
SLOTTED HEX SCREW Not Available This part replaces BS-93496. Price: |
| 80 |
IH-77674-C1 |
LINK Not Available Price: |
| 81 |
BS-792813 |
Spring-Governor (Brown) This part replaces BS-261306. Price: $5.76 |
| 82 |
BS-261197 |
GOVERNOR SPRING Not Available Price: |
| 83 |
IH-76586-C1 |
Washer, Governor Crank Price: Call Us |
| 84 |
BS-692012 |
Governor Crank This part replaces BS-231058. Price: $47.28 |
| 85 |
BS-391733 |
LEVER Not Available Price: |
| 86 |
BS-92613 |
BOLT Not Available Price: |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 87 |
BS-231082 |
HEX NUT Not Available Price: |
| 88 |
BS-93686 |
Screw, Governor Control Plate Mounting Price: Call Us |
| 89 |
BS-231039 |
Spacer Price: Call Us |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532400725. Price: $4.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
