| Ref | Part Number | Description |
|---|
| 1 |
3219-2 |
NUT-HEX Price: $0.37 |
| 1 |
MA-19615022000 |
DASH PANEL Not Available Price: |
| 2 |
MA-10352838000 |
COVER-RIGH Not Available Price: |
| 3 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 3 |
MA-10302867000 |
GLASS Not Available Price: |
| 4 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 4 |
MA-10302868000 |
PACKING Not Available Price: |
| 5 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 6 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 7 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 7 |
MA-19615023100 |
METER-TACH Not Available Price: |
| 8 |
MA-10352837200 |
METER-TEMPERATURE Not Available Price: |
| 9 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 9 |
MA-10352837300 |
METER-FUEL Not Available Price: |
| 10 |
None |
Case |
| 10 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 11 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 11 |
MA-19615023500 |
MONITOR (LH) Not Available Price: |
| 12 |
MA-19615023600 |
MONITOR (RH) Not Available Price: |
| 13 |
None |
Meter, Design |
| 13 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 14 |
86-7230 |
GEAR-INPUT, TRANSMISSION Price: $610.12 |
| 15 |
None |
Harness |
| 15 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 16 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 16 |
MA-09808120348 |
BULB Not Available Price: |
| 17 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 18 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 18 |
MA-H2420103020 |
SCREW W/WASHER Not Available Price: |
| 19 |
None |
Clamp |
| 19 |
3210-8 |
SCREW-HH Price: $1.02 |
| 20 |
None |
Clamp |
| 20 |
71-4350 |
NUT Price: $3.46 |
| 21 |
83-5130 |
SPACER-PINION Price: $87.56 |
| 21 |
MA-04322104014 |
TAP SCREWP Not Available Price: |
| 22 |
72-3572 |
SHIM-BEARING, FRONT (.098) This part replaces 72-3570. Price: $23.68 |
| 22 |
72-3573 |
SHIM-BEARING, FRONT (.100) Price: $24.63 |
| 22 |
72-3598 |
SHIM-BEARING, FRONT (.149) Price: $24.63 |
| 23 |
254-91 |
CONE-BEARING Price: $18.65 |
| 24 |
254-90 |
BEARING-CUP This part replaces 21-8390. Price: $11.29 |
| 25 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 25 |
MA-19632916000 |
SWITCH COMBINATION Not Available This part replaces MA-19632915000. Price: |
| 26 |
93-3619 |
UPPER HOUSING ASM Price: $1,825.32 |
| 26 |
MA-19632916300 |
LABEL, LAMP Not Available Price: |
| 27 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 27 |
MA-19615031000 |
PLATE-SIGN Not Available Price: |
| 28 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 28 |
MA-19632918000 |
SWITCH LIGHT H Not Available Price: |
| 29 |
MA-19615024000 |
BOOT-SWITCH Not Available Price: |
| 30 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 30 |
MA-27601207000 |
LINER Not Available Price: |
| 31 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 32 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 32 |
MA-19615032000 |
SWITCH ASSEMBLY Not Available Price: |
| 33 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 33 |
MA-A2420103006 |
SCREW Not Available Price: |
| 34 |
75-0721 |
DISCONTINUED Price: Call Us |
| 34 |
MA-19615035000 |
KNOB Not Available Price: |
| 35 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 35 |
MA-04322104014 |
TAP SCREWP Not Available Price: |
| 36 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 36 |
MA-10352857000 |
KNOB Not Available Price: |
| 37 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 37 |
MA-19615033000 |
BRACKET-SWITCH Not Available Price: |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 38 |
MA-19615026000 |
MARK Not Available Price: |
| 39 |
72-9420 |
VENT Price: $6.85 |
| 39 |
MA-19615027000 |
MARK Not Available Price: |
| 40 |
83-4910 |
COUPLER-PINION Price: $223.04 |
| 40 |
MA-19615029000 |
MARK Not Available Price: |
| 41 |
71-4330 |
SEAL Price: $36.26 |
| 42 |
MA-F0500406016 |
BOLT Not Available Price: |
| 43 |
MA-35259242800 |
SEAL Not Available Price: |
| 45 |
MA-19652969000 |
SWITCH ASSEMBLY-IGNITIO This part replaces MA-10312889000. Price: $104.09 |
| 46 |
MA-10253507100 |
IGNITION KEY This part replaces MA-27800501200. Price: $22.77 |
| 47 |
MA-10253509000 |
TUBE Not Available Price: |
| 503712201 |
503712201 |
BEARING Price: $11.99 |
| 503940201 |
503940203 |
BEARING CAP This part replaces 503940201. Price: $29.99 |
| 503940501 |
503940501 |
CUP Price: $9.99 |
| 537128173 |
537128105 |
CRANKSHAFT ASSY This part replaces 537128173. Price: $98.99 |
