| Ref | Part Number | Description |
|---|
| 0 |
632782 |
CARBURETOR Price: $73.86 |
| 1 |
631255 |
SHAFT & LEV Price: $6.36 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 10 |
631302 |
SHAFT & LEV Price: $6.11 |
| 11 |
631476 |
RET SPRING Price: $1.22 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
631890 |
SHUTTER Price: $1.20 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
632281 |
IDLE SCREW Price: $2.60 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
630740 |
O RING Price: $1.49 |
| 25 |
631700 |
FLOAT BOWL Price: $2.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 40 |
632368 |
POWER SCREW Price: $10.46 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
631334A |
GASKET Price: $2.25 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 501517201 |
501517201 |
CHAIN GUIDE Price: $4.99 |
| 501768001 |
501768001 |
PIVOT SLEEVE R Price: $4.99 |
| 501768101 |
501768101 |
PIVOT SLEEVE L Price: $6.99 |
| 501874701 |
501874701 |
SPRING Price: $3.99 |
| 501874901 |
503802701 |
PIVOT PIN This part replaces 501874901. Price: $4.99 |
| 501875301 |
501875301 |
KNEE-JOINT Price: $19.99 |
| 501915803 |
503768101 |
DECAL This part replaces 501915803. Price: $3.99 |
| 503220001 |
503220001 |
NUT M8 FLANGE Price: $2.99 |
| 503222001 |
503222302 |
LOCKNUT This part replaces 503222001. Price: $3.99 |
| 503465901 |
503465901 |
SPRING Price: $6.99 |
| 503493401 |
503493401 |
LOCK SPRING Price: $4.99 |
| 503572801 |
503736601 |
CHAIN BRAKE This part replaces 503572801. Price: $119.99 |
| 503572901 |
503572901 |
CLUTCH COVER Price: $53.73 |
| 503573001 |
503573001 |
Price: $4.69 |
| 503573101 |
503573101 |
PROTECTOR Price: $6.63 |
| 503573201 |
503727401 |
HANDGUARD This part replaces 503573201. Price: $37.99 |
| 503590701 |
503590701 |
FELLING DOG Price: $19.99 |
| 720123300 |
720123300 |
PIN 3X10 Price: $2.99 |
| 721425250 |
721425250 |
SPIRAL PIN 4X12 Price: $2.99 |
| 725529356 |
725529356 |
SCREW MC6S 4X16 Price: $4.99 |
| 725532756 |
725532755 |
SCREW MC6S 5X12 This part replaces 725532756. Price: $2.99 |
| 729571305 |
503212810 |
SCREW This part replaces 729571305. Price: $2.99 |
| 735310820 |
735310820 |
E-RING 4 Price: $2.99 |
