| Ref | Part Number | Description |
|---|
| 1 |
170551 |
Control Th/ch Flag Price: Call Us |
| 1 |
925-04004 |
HEADLIGHT ASSEMBLY Not Available This part replaces 625-04004. Price: |
| 1 |
925-05055 |
HEAD LAMP BULB ASSEMBLY This part replaces 725-04084. Price: $41.63 |
| 1 |
94-3004 |
SHAFT-DRIVE, SPLINED Price: $564.48 |
| 2 |
105-2851 |
BACKPLATE ASM Price: $613.67 |
| 2 |
17720408 |
Screw Hex Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 2 |
703-05143-0637 |
SHIELD-RNGBRD (LH) (POWDER BLACK) Not Available Price: |
| 3 |
105-2852 |
HOUSING ASM Price: $1,206.90 |
| 3 |
703-05145-0637 |
RUNNING BOARD SHIELD (RH) (POWDER BLACK) Not Available Price: |
| 4 |
179758 |
Muffler Exhaust B&S Price: Call Us |
| 4 |
703-05652-0637 |
HINGE BRACKET (RH) (POWDER BLACK) Not Available Price: |
| 4 |
76-6910 |
ROTATING KIT Price: $2,143.15 |
| 5 |
703-05653-0637 |
HINGE BRACKET (LH) (POWDER BLACK) Not Available Price: |
| 5 |
76-6970 |
INSERT-PLATE, CAM Price: $140.84 |
| 6 |
703-05655A-0637 |
HOOD MOUNTING BRACKET (POWDER BLACK) This part replaces 703-05655-0637. Price: $50.59 |
| 7 |
703-3394-0637 |
INTAKE SCREEN Not Available This part replaces 703-3394. Price: |
| 7 |
94-3002 |
SCREW-CAP Price: $7.19 |
| 8 |
106-6876 |
SEAL KIT Price: $48.83 |
| 8 |
703-3764-0637 |
Bracket, Panel Mtg. Price: Call Us |
| 9 |
703-3765-0637 |
Shield, Lower Heat Price: Call Us |
| 10 |
710-04164 |
Screw, Hex Wash Hd, #8-18 x .375 Price: $3.99 |
| 10 |
76-6950 |
RACE-THRUST This part replaces 60-6160. Price: $25.65 |
| 11 |
710-0473 |
Screw, Truss Hd, 10-24 x .5 Price: $3.90 |
| 12 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 12 |
94-3003 |
PLATE-VALVE Price: $515.64 |
| 13 |
165291 |
Gasket Eng 1 313 Id Tin Plated Price: Call Us |
| 13 |
710-0607 |
Screw, Hex Wash Hd Tapp 5/16-18 x . Price: $6.06 |
| 13 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 14 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 14 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 15 |
710-0895 |
Screw, Hex Wash. Hd. 1/4-20 x .75 Price: $5.82 |
| 16 |
710-1220 |
Screw, Truss Phil. Hd. 12-16 x .75 Price: $3.96 |
| 17 |
710-3015 |
Screw, Hex Cap, 1/4-20 x .75 GR5 Price: $3.65 |
| 18 |
710-3170 |
SCREW 5/16-18 x .56 Not Available Price: |
| 19 |
712-0272 |
Nut, Hex Sems, 10-24 Price: $3.58 |
| 20 |
712-04063 |
Nut, Hex Insert Flange Lock, 5/16-18 Price: $3.56 |
| 21 |
712-04064 |
Nut, Hex Insert Flange Lock, 1/4-20 Price: $3.64 |
| 22 |
712-04065 |
Nut, Hex Insert Flange Lock, 3/8-16 Price: $3.68 |
| 23 |
169837 |
Shield BRN/DBR Guard Price: Call Us |
| 23 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 24 |
726-0233 |
Nut, Push, .25 ID Price: $3.93 |
| 25 |
727-3194 |
Cylinder, Gas Spring Price: $106.14 |
| 26 |
931-04211 |
HEAD LIGHT BEZEL Not Available This part replaces 731-04211. Price: |
| 27 |
731-05161 |
HOOD COVER Not Available Price: |
| 29 |
137180 |
Kit Spark Arrestor (Flat Scrn) Price: Call Us |
| 29 |
732-04281A |
Spring, Torsion Price: $7.44 |
| 30 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 31 |
187750 |
Tank Fuel Front Price: Call Us |
| 31 |
736-3090 |
Washer, Flat, .26 x .72 x .060 Price: $5.79 |
| 32 |
140527 |
Cap Asm Fuel Price: Call Us |
| 32 |
738-0380 |
Screw, Shoulder, .5 x .27 Lg 3/8-16 Price: $7.34 |
| 33 |
123487X |
Clamp Hose Price: Call Us |
| 33 |
747-1323A |
Rod, .25 x 4.55 Price: $10.76 |
| 34 |
783-04714A |
LATCH PLATE This part replaces 783-04714. Price: $17.27 |
| 37 |
137040 |
Line Fuel 20" Price: Call Us |
| 38 |
181654 |
Plug Drain Oil Price: Call Us |
| 40 |
124028X |
Bushing Snap Nyl Blk Fuel Line Price: Call Us |
| 44 |
17670412 |
Screw Thdrol 1/4-20 x 3/4 Price: Call Us |
| 45 |
17000612 |
Screw Hex Wsh Thdrol 3/8-16 Price: Call Us |
| 46 |
19091416 |
Washer 9/32 x 7/8 x 16 Ga. Price: Call Us |
| 62 |
10040500 |
Washer Lock 5/16 Price: Call Us |
| 72 |
71070512 |
Screw Hex Head Cap 5/16-18 x 3/4 Price: Call Us |
| 78 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
